HAYWARD POOL P ARTS
STAR-CLEAR II CARTRIDGE FILTER PARTS
SKU Number Description List Price Code
1 CX800-G ................ Locking Knob ..............................................................$ 36.46 C
2 CX250-Z-7.............. O-Ring.........................................................................$ 3.84 C
3 ECX1322-A ............ Vent Valve with O-Ring (1989)....................................$ 9.82 C
4 CX800-C................. Filter Head (Cover) with Air Relief Valve.....................$ 146.10 C
5 CX800-F ................. Filter Head O-Ring ......................................................$ 41.96 C
6A CX800-Z2 ............... Tie Rod (C800)............................................................$ 160.74 C
6B CX1100-Z2 ............. Tie Rod (C1100)..........................................................$ 163.40 C
7A CX800-AA .............. Filter Tank Body, 1½” (C800) ......................................$ 698.40 C
7B CX1100-AA ............ Filter Tank Body, 1½” (C1100).....................................$ 796.04 C
7C CX1500-AA ............ Filter Tank Body, 1½” (C1500) ....................................$1,043.86 C
8 ECX27091 .............. Pressure Gauge..........................................................$ 35.66 C
9 CX250-Z14A .......... Drain Plug Kit (Inc Plug and O-Ring) ..........................$ 7.72 C
10 CX800-HA .............. Check Valve Assembly (Optional)...............................$ 40.24 C
11A CX800-Z4 ............... Auto Air Relief Tube (C800) ........................................$ 11.18 C
11B CX1100-Z4 ............. Auto Air Relief Tube (C1100).......................................$ 13.42 C
STAR-CLEAR CARTRIDGE FILTER PARTS
SKU Number Description List Price Code
1 CX250-G ................ Locking Knob ..............................................................$ 26.58 C
2 CX250-Z-7 .............. O-Ring.........................................................................$ 3.84 C
3A ECX1322-A ............ Vent Valve with O-Ring ...............................................$ 9.82 C
3B SPX1082-Z410 ....... Relief Valve O-Ring (Set of 10)...................................$ 9.08 C
4 CX250-C................. Filter Head (Dome) with Air Relief Valve.....................$ 114.14 C
5 CX250-F ................. Filter Head Gasket ......................................................$ 31.96 C
6A CX250-Z2S............. Tie Rod (C250), 18-9/32” ............................................$ 73.92 C
6B CX500-Z2S............. Tie Rod (C500), 28-3/32” ............................................$ 102.16 C
6C CX750-Z2S............. Tie Rod (C750, C100), 38-1/16”..................................$ 123.72 C
7A CX250-AA1 ............ Filter Body with Tie Rod Assembly (C250)..................$ 428.02 C
7B CX500-AA1 ............ Filter Body with Tie Rod Assembly (C500)..................$ 518.14 C
7C CX750-AA1 ............ Filter Body with Tie Rod Assembly (C750,C100) ........$ 638.34 C
8A ECX270861 ............ Pressure Gauge (1991 and prior) ...............................$ 32.88 C
8B ECX27091 .............. Pressure Gauge, Back Mount.....................................$ 35.66 C
9A ECX1322-A ............ Vent Valve with O-Ring ...............................................$ 9.82 C
9B CX250-Z14A .......... Drain Plug Kit ..............................................................$ 7.72 C
10 ECX4077-B1 .......... Check Valve (Optional) ...............................................$ 25.64 C
MICRO STAR-CLEAR CARTRIDGE FILTER PARTS
SKU Number Description List Price Code
C120, C200, C225
1 CX120-AA .............. Filter Head with Vent Valve - 1½” NPT........................$ 81.26 C
2 CX120-D................. O-Ring.........................................................................$ 17.24 C
3 CX120-B................. Filter Body Housing.....................................................$ 100.30 C
4 ECX1322-A ............ Vent Valve with O-Ring ...............................................$ 9.82 C
- CX250-Z15 ............. By-Pass Plug (Internal) ...............................................$ 1.80 C
5 SPX1485-C ............ Gasket.........................................................................$ 5.88 C
SPX1485-B ............ Elbow Union................................................................$ 33.92 C
