Butt’s Pumps and Motors - page 938

phone: 1-800-678-7178 fax: 1-800-270-9342
www.centralspasupply.com - 205 - Central Spa & Pool Supply Ltd.
© 2012
HAYWARD POOL P ARTS
TURBO-FLO LX SERIES - SP2080, SP2080X15
SKU Number Description List Price Code
1 SPX1500-D2A ........ Strainer Cover with O-Ring .........................................$ 51.98 C
2 SPX1500-P............. Strainer Cover O-Ring ................................................$ 11.18 C
4 SPX1250-RA.......... Strainer Basket ...........................................................$ 15.64 C
5 SPX1500-CAP ....... Strainer Housing with Basket......................................$ 79.42 C
6 SPX1700FGV ......... Drain Plug with Gasket ...............................................$ 6.98 C
8 SPX1500-N2 .......... Bolt, No. 10-24 Hex. Head ..........................................$ 3.02 C
9 SPX1580-Z-1.......... Housing O-Ring ..........................................................$ 13.48 C
10 SPX1500-KA.......... Seal Assembly ............................................................$ 42.88 C
11 SPX1500-Y2........... Nut, No. 10-24 Hex. ....................................................$ 2.10 C
12 SPX1500-F ............. Impeller, 3/4 HP...........................................................$ 43.94 C
13 ECX1325 ................ Switch Assembly .........................................................$ 22.10 C
ECX13252 .............. Switch Assembly .........................................................$ 35.40 C
14 SPX1700-FG .......... Drain Plug (optional) ...................................................$ 5.80 C
15 SPX1580-BP .......... Housing Cover ............................................................$ 86.40 C
1
2
4
15
8
9
12
13
11 23
10
5
6
6 / 14
10
15
8
9
11
17
16
7
5
1
2
3
TURBO-FLO SERIES - SP2000, SP2100
SKU Number Description List Price Code
3 SPX1500-LX .......... Basket .........................................................................$ 19.16 C
7 SPX1500-W............ O-Ring.........................................................................$ 5.00 C
18 SPX1500-RA.......... Check Valve Assembly................................................$ 32.88 C
19 SPX1500-B ............ Housing Cover ............................................................$ 59.46 C
19 SPX1705-B ............ Housing Cover with Integral Diffuser ..........................$ 76.76 C
(SP-2100 Series, Turbo-Flo II)
20 SPX1705-Z-1.......... Housing O-Ring Gasket (SP-2100 Series) .................$ 18.30 C
21 SPX1707-C ............ Impeller, 3/4 HP (SP-2100 Series,Turbo-Flo II) .........$ 45.60 C
23 SPX1500-AA.......... Pump Housing (SP-2000 Series)................................$ 86.64 C
23 SPX1705-AA.......... Pump Housing (SP-2100 Series)................................$ 97.64 C
ULTRA-PRO SERIES - SP2290, SP2295
SKU Number Description List Price Code
16 SPX1500-E............. Impeller, 1/2 HP...........................................................$ 41.96 C
17 SPX1580-AAP ....... Pump Housing ............................................................$ 103.94 C
POWER FLO SERIES
20 SPX1500-H ............ Housing Gasket (Power Flo only) ...............................$ 12.60 C
SPX1705-C ............ 1/2 HP Impeller (Power Flo II & III) .............................$ 43.94 C
SPX1500-L ............. 1 HP Impeller (Power Flo & Power Flo LX).................$ 45.60 C
SPX1500-LH .......... 1 HP Impeller (Power Flo LX Hi Performance) ...........$ 45.60 C
SPX1711-C............. 1 HP Impeller (Power Flo)...........................................$ 47.34 C
SPX1580-CH.......... 1.5 HP Impeller (Power Flo LX Hi Performance) ........$ 45.92 C
SPX1525-CH.......... 2 HP Impeller (Power Flo LX Hi Performance) ...........$ 48.58 C
SPX1720KA ........... Hayward Seal (Power Flo III) ......................................$ 47.34 C
SPX1501-BT .......... 1500 UN Housing Cover (Power Flo) .........................$ 61.50 C
SPX1501-AAT ........ 1500 UN Pump Housing (Power Flo)..........................$ 90.54 C
SPX1580-AAT ........ Unioned Rear Housing (Power Flo & Power Flo LX) ..$ 103.94 C
SPX1520-BT .......... Housing Front (Power Flo LX) ....................................$ 89.06 C
SPX1580-B ............ Unioned Front - Before 1997 (Power Flo)...................$ 71.50 C
SPX3005-R ............ Seal Ring (Power Flo LX) ...........................................$ 7.98 C
SPX1250-Z4........... Strainer Knob (Power Flo II & III) ................................$ 14.40 C
1
2
3
8
12 / 21
6 / 14
18
18
20
19
7
13
10
11
5
23
