HAYWARD PRO SERIES SAND FILTERS PARTS
SKU Number Description List Price Code
S180T, S210T, S220T, S244T
1 SP0714-T ............... Vari-Flo XL Control Valve 1½”.....................................$ 214.50 C
2 ECX270861 ............ Pressure Gauge..........................................................$ 32.88 C
3 GMX600-F .............. Valve / Tank O-Ring ....................................................$ 22.74 C
4 GMX600-NM .......... Flange Clamp, Noryl ...................................................$ 58.34 C
5 SX202-S ................. Sand Shield (1997- ) ...................................................$ 1.80 C
6A SX180-DA .............. Folding Umbrella Lateral Assembly ............................$ 110.68 C
with Center Pipe (S180T) (1997 - )
6B SX210-DA .............. Folding Umbrella Lateral Assembly ............................$ 120.08 C
with Center Pipe (S210T) (1997 - )
6C SX220-DA .............. Folding Umbrella Lateral Assembly ...........................$ 123.54 C
with Center Pipe (S220T) (1997 - )
6D SX244-DA .............. Folding Umbrella Lateral Assembly
with Center Pipe (S244T) (1997 - ).........................$ 130.84 C
7A SX210-AA1 ............ Filter Tank with Skirt, Drain, Lateral Assembly............$ 902.66 C
(S210T)
7B SX220-AA1 ............ Filter Tank with Skirt, Drain, Lateral Assembly............$ 985.96 C
(S220T)
8A SX200-Q ................. Lateral (S180T) ...........................................................$ 6.98 C
8B SX240-D ................. Lateral (S210T, S220T, S244T)...................................$ 7.04 C
9 SX180-G ................. Gasket.........................................................................$ 2.90 C
10 SX180-H ................. Drain Cap....................................................................$ 4.82 C
SX180-HG .............. Drain Cap Kit (Includes #9 & 10) ................................$ 7.04 C
MULTI-PORT VALVES
SKU Number Description List Price Code
SP07122 ................. Vari-Flo Control Valve Assembly.................................$ 188.56 C
SP0710XALL ......... Vari-Flo Control Valve 1½” ..........................................$ 162.10 C
SP0710X62 ............ Vari-Flo Valve Assembly 1½" ......................................$ 237.14 C
1 SPX0710-XF .......... Handle.........................................................................$ 19.16 C
SPX0715-F ............. Handle.........................................................................$ 26.58 C
2 SPX0710-XZ7 ........ Handle Pin ..................................................................$ 6.98 C
3 SPX0710-Z16 ......... Non-Metallic Bearing...................................................$ 4.82 C
4 SPX0714-BA .......... Key, Cover and Handle Assembly...............................$ 146.84 C
5 SPX0714-Z1 ........... Cover Screw (Set of 6)................................................$ 17.12 C
6 SPX0714-L ............. Cover O-Ring ..............................................................$ 9.82 C
7 SPX0735-GA .......... O-Ring Shaft Seal Assembly.......................................$ 8.28 C
8 SPX0710-Z62 ......... Spring Washers (Set of 2)...........................................$ 6.98 C
9 SPX0714-CA .......... Key/Seal Assembly .....................................................$ 52.96 C
10 SPX0714-D ............ Diffuser........................................................................$ 50.24 C
11 SPX0714-A ............ Valve Body with Gasket & Sight Glass........................$ 222.24 C
12 SPX0710-MA ......... Sight Glass with O-Ring..............................................$ 9.46 C
SPX0710R.............. Gasket - Sight Glass ...................................................$ 2.28 C
SPX0710-XD .......... Gasket - 5-Spoke ........................................................$ 23.80 C
13 SPX0710-XZ3 ........ Cover O-Ring ..............................................................$ 9.82 C
14 SPX0603S .............. Spring..........................................................................$ 17.24 C
15 SPX0733-D ............ Handle.........................................................................$ 14.84 C
16 SPX0733-H ............ Handle Pin ..................................................................$ 5.74 C
17 SPX0733-J ............. Handle Spring .............................................................$ 6.98 C
18 SPX0733-B ............ 3-Way Cover with Label..............................................$ 20.82 C
19 SPX0733-Z3A ........ Cover Screw (Set of 8)................................................$ 10.76 C
20 SPX0733-Z2A ........ O-Ring, Cover, Washer & Spacer Set.........................$ 10.38 C
21 SPX0733-Z1A ........ O-Ring, Key with Washer............................................$ 8.28 C
22 SPX0733-E............. Seal.............................................................................$ 9.46 C
23 SPX0733-CA .......... Key & Seal Assembly with O-Ring ..............................$ 41.84 C
SPX0733-Z1 ........... O-Ring, Key ................................................................$ 5.88 C
SPX0710-Z9 ........... Rubber Adhesive.........................................................$ 49.32 C
SPX0710-XBA17 ... Key Cover and Handle - Black....................................$ 146.78 C
SPX0715-C ............ Key, Valve (SP0715/16) ..............................................$ 80.46 C
10
9
8A,8B
6A
6B
6C
6D
7A
7B
4
1
2
3
5
SP0714-T
see detailed
parts list, below
SP0733-S
SP0710-X
SP0714-T
22
19
18
16 17 15
2
12
3
20
14
7
19
1
1
2
3
4
5
6
7
8
9
10
12
11
8
21
23
