The pump you trust.
Convertible MJ
The MJ injection centrifugal pumps are exceptionally reliable and efficient. Specially designed for domestic
purposes, they can also be used to pump water from wells, streams, ponds and many other sources of water.
Molded in Noryl, the high-precision impeller assures the MJ models an optimum efficiency. To eliminate all
vibrations, the impeller is screwed to the shaft of the motor.
Its stainless steel disc distinguishes this pump from any other. In fact, this innovation facilitates maintenance
and minimises corrosion.
The housing and the motor bracket are made of grey cast iron and are machined with such precision that it
maximizes considerably the performance. These parts are then treated with 2 layers of paint that gives superior
resistance to corrosion.
Part
number
Model
Motor
H.P. (kW)
Suction
inch (mm)
Discharge
inch (mm)
Length
in (cm)
Shipping weight lbs
(kg)
513-0020
MJ-50
1/2 (.37)
1 ¼" (31.75)
1" (25.4)
14.50 (36.9)
46 (21)
513-0030
MJ-75
3/4 (.55)
1 ¼" (31.75)
1" (25.4)
14.75 (37.5)
50 (23)
513-0040
MJ-100
1.0 (.75)
1 ¼" (31.75)
1" (25.4)
15.00 (38.1)
52 (24)
9 po
(22.9 cm)
9 ¾ po
(24.9 cm)
L
•
Single-phase motor,
"J-face" flange
, 3450 RPM, 60
hz, 115/230 Volts, automatic thermal protection and
stainless steel shaft.
•
Internal disc for easy maintenance
•
Pressure switch 30/50 lbs/in
2
•
Pressure gauge 0 - 100 P.S.I.
•
Ejector not included.
All pumps are tested at our factory.
Also available: other voltages and TEFC motors
