The pump you trust.
Convertible PJC
The PJC injection centrifugal pump with convertible
ejector is built for either shallow or deep well
applications. It is ideal for a summer cottage or a
country house.
The diffuser (Polycarbonate) and the impeller (Noryl)
precisely molded, assure optimum efficiency. The
self-lubrificated mechanical seal is made of carbon
and ceramic for a longer life span.
The pump housing and the seal plate are made of
grey close-grained cast iron. These parts are
specially treated with adapted paint to give a higher
resistance to corrosion.
SHALLOW WELL EJECTOR KITS
(included: ejector body, venturi tube, nozzle, ejector
gasket, bolts and washers)
Part
number
Model
H.P.
Diameter
Venturi Nozzle
325-0250
PJC-7-50S
1/2
29/64
16/64
325-0275
PJC-7-75S
3/4
32/64
16/64
325-0300
PJC-7-100S
1
34/64
16/64
15 po
(38.1 cm)
8 ¼ po
(20.8 cm)
9 ½ po
(24.1 cm)
Part
number
Model
Motor
H.P. (kW)
Suction
inch (mm)
Discharge
inch (mm)
Shipping weight
lbs (kg)
325-0050
PJC-50
1/2 (.37)
1 ¼" (31.8)
1" (25.4)
42 (19)
325-0075
PJC-75
3/4 (.55)
1 ¼" (31.8)
1" (25.4)
42 (19)
325-0100
PJC-100
1.0 (.75)
1 ¼" (31.8)
1" (25.4)
44 (20)
Shallow well
ejector included
+ deep well
CHARACTERISTICS
•
Single-phase motor,
square flange
, 3450 RPM,
115/230 Volts, automatic thermal protection and
stainless steel shaft
•
Rubber seal gasket
•
Pressure switch set at 30 to 50 lbs/in²
•
0 - 100 PSI pressure gauge
•
Shallow well ejector included
•
Deep well venturi included
•
Convertible ejector for deep well application
All pumps are tested at our factory
