Butt’s Pumps and Motors - page 993

The pump you trust.
Self priming centrifugal PLSH
Ideal for lawn sprinkling systems, irrigation and
other areas where high capacity self-priming
pumps are required.
Part
number
Model
Motor
HP (kW)
Suction
Inch (mm)
Discharge
Inch (mm)
Shipping weight
lbs (kg)
335-0075
PLSH-75
3/4 (.55)
1 ½" (38.10)
1 ½" (38.10)
63 (29)
335-0100
PLSH-100
1.0 (.75)
1 ½" (38.10)
1 ½" (38.10)
65 (30)
335-0150
PLSH-150
1.5 (1.1)
1 ½" (38.10)
1 ½" (38.10)
70 (32)
335-0200
PLSH-200
2.0 (1.5)
1 ½" (38.10)
1 ½" (38.10)
75 (34)
FEATURES
On site maintenance possible due to an easy access to internal parts.
Maximum water volume in pump housing assures easy and fast priming.
Unique design of housing and polycarbonate + fiber impeller helps provide high heads.
Hard to unprime even with bubbles in the water.
Long life assured by non-corrosive paint and strong construction.
CHARACTERISTICS
Single phase motor,
square flange
, 60 Hz, 115/230 Volts, capacitor starting, automatic thermal protection
Priming up to 25 feet
(7.62 m)
All pumps are tested at our factory
17 po
(43.2 cm)
10 ¼ po
(26.0 cm)
10 po
(25.4 cm)
