90
Refrigeration
Magnetic Gaskets Straight Lengths
Roll-In Flange
5/16" Magnet
Part #
Description Length
81-P2208-8
9/16" to 3/4"
clearance
8'
3/8" Magnet
Part #
Description Length
81-P2778-8
5/16" to 1/2"
clearance
8'
1/2" Magnet
Part #
Description Length
81-P2209-8
7/16" to 5/8"
clearance
8'
5/8" Magnet
Part #
Description Length
81-P2421-8
*
7/16" to 5/8"
clearance
8'
* Note: Bottom flange straightens out to horizontal
position when inserted in retainer strip. Width dimension
shown is that when gasket is in assembled position on
completed unit.
Description
Commercial gaskets designed for use on
those refrigerator doors having retainer strips
imbedded in the foamed-in-place insulation. No
fasteners needed. Easy replacement, special
arrowhead on gasket underside holds gasket
securely in place. No special tools required.
Simply install gasket by rolling it into retainer
strip opening. Just use an ordinary seam
wallpaper roller to do the job.
Conventional Flange
5/16" Magnet
Part #
Description Length
81-P1943-8
7/16" to 5/8"
clearance
8'
5/16" Magnet
Part #
Description Length
81-P2099-8
11/16" to 7/8"
clearance
8'
1/2" Magnet
Part #
Description Length
81-P10698
1/2" to 9/16"
clearance
14'
1/2" Magnet
Part #
Description Length
81-P2319-8
11/16" to 1/8"
clearance
8'
5/8" Magnet
Part #
Description Length
81-P11026
9/16" to 3/4"
clearance
14'
Magnetic Gaskets Straight Lengths
Description
• Gaskets designed for heavy duty (wide
magnets) and medium to light duty (narrow
gaskets) applications.
81-P10698
Illustrated
81-P2209-8
Illustrated
Gaskets
