88
Refrigeration
81-CV1402
Illustrated
81-CV1402
15/32" Cushion Height
"Curvall" Gaskets
Description
• Extruded rubber gasket specially designed to fit
around curved corners without notching
• 14' lengths - also fit on straight sections.
"Curvall" Gaskets
Part #
Description Length
81-CV1402
Rubber
14'
81-CV1410
Rubber
14'
When determining the cushion height for your
application, the gasket cushion should be
compressed a minimum of 1/8" (0.3cm) to a
maximum of 3/16" (0.5cm) to obtain the most
efficient seal.
81-CV1410
18/32" Cushion Height
18/32"
3/4"
1/2"
Direct Replacement Gasket - Anthony Glass Doors
81-4505
Illustrated
Description
Made from tooling designed for the original equipment manufacturer. Furnished
in a set of four L-shaped sections with factory welded corners, with the magnet
furnished in a coil inside box. The four L-shaped sections will accommodate the
largest size door made in regular production.
Anthony Glass Door Gaskets
Part #
Description
81-4505
Maximum frame size 30" to
77" clearance.
Sectional Cooler Sealing Strips
Description
• Designed for joining walk-in freezer and cooler sectional panels.
• Provides excellent thermal barrier.
• Can be used for a wide variety of other sealing and insulation applications.
• Easy to apply pressure sensitive adhesive on bottom side.
Sectional Cooler Sealing Strips
Part # Description Width Height Length
81-P2490
Extruded vinyl
1/2"
3/16"
540'
81-1812
Extruded rubber 1 5/8"
1/8"
750'
81-P2490
Illustrated
81-1812
Illustrated
Pressure Sensitive
Adhesive Backing
Pressure Sensitive
Adhesive Backing
Weather Sealing Strips
Part #
Description
Dimensions
70-WS2
Foam
72" × 11⁄2" × 3/4"
Weather Sealing Strips
70-WS2
Illustrated
Gaskets
