91
Refrigeration
Magnet-All/ Compression-All Gaskets
Conventional Flange - Narrow Magnet
Part # Description
Max Frame
Size
81-2303
5/8" to 13/16"
clearance
32" × 56"
81-2304
37" × 87"
Part # Description
Max Frame
Size
81-2604
11/16" to 13/
16" clearance
37" × 87"
Part # Description
Max Frame
Size
81-2001
11/16" to 7/8"
clearance
20" × 32"
81-2002
32" × 42"
81-2003
32" × 56"
81-2004
37" × 87"
Conventional Flange - Wide Magnet
Part # Description
Max Frame
Size
81-3103
1/2" to 9/16"
clearance
32" × 56"
81-3104
37" × 87"
Part # Description
Max Frame
Size
81-3003
9/16" to 3/4"
clearance
32" × 56"
81-3004
37" × 87"
Part # Description
Max Frame
Size
81-3203
11/16" to 7/8"
clearance
20" × 32"
81-3204
32" × 42"
Magnetic-All & Compression-All
gaskets are furnished in sets of four
L-shaped sections with factory welded
corners. A Magnet coil sufficient for
maximum size indicated is included
with each kit.
Magnet-All/ Compression-All Gaskets
Magnet-All and Compression-All gaskets are designed
as universal replacement door gaskets.
* Note:
Bottom flange straightens out to horizontal
position when inserted in retainer strip. Width
dimension shown is that when gasket is in
assembled position on completed unit.
Roll-In Flange - Narrow Magnet
Part # Description
Max Frame
Size
81-2703
* 5/16" to 1/2"
clearance
32" × 56"
81-2704
*
37" × 87"
Roll-In Flange - Wide Magnet
Part # Description
Max Frame
Size
81-3303
* 7/16" to 5/8"
clearance
32" × 56"
81-3304
*
37" × 87"
Part # Description
Max Frame
Size
81-3403
* 7/16" to 5/8"
clearance
32" × 56"
81-3404
*
37" × 87"
* Note:
Bottom flange straightens out to horizontal
position when inserted in retainer strip. Width
dimension shown is that when gasket is in
assembled position on completed unit.
81-3403
Illustrated
Gaskets
