Magnetic Gasket Kits
A
B
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
C
B
A
C
B
A
C
B
AllSEAL Kits Include
• 4 "L" shaped gasket sections with factory welded
corners.
• Sufficient magnet for the maximum size.
• One tube of glue for centre welds.
Foster
Part # Maximum Frame Size
81-MK2421G-9 50.8cm × 76.2cm (20" × 30")
81-MK2421G-14 81.3cm × 121.9cm (32" × 48")
81-MK2421G-18 81.3cm × 182.9cm (32" × 72")
A: 1.7cm (11/16") B: 1.3cm (1/2") C: 3cm (1 3/16")
Foster
Part # Maximum Frame Size
81-MK3265G-9 50.8cm × 76.2cm (20" × 30")
81-MK3265G-14 81.3cm × 121.9cm (32" × 48")
81-MK3265G-18 81.3cm × 182.9cm (32" × 72")
A: 1.7cm (11/16") B: 1.3cm (1/2") C: 3cm (1-3/16")
Anthony • Hussmann
Part # Maximum Frame Size
81-MK4505B-9 50.8cm × 76.2cm (20" × 30")
81-MK4505B-14 81.3cm × 121.9cm (32"× 48")
81-MK4505B-18 81.3cm × 182.9cm (32" × 72")
A: 1.7cm (11/16") B: 0.5cm (3/16")
Universal
Part # Maximum Frame Size
81-MK453W-9 50.8cm × 76.2cm (20" × 30")
81-MK453W-14 81.3cm × 106.7cm (32" × 42")
81-MK453W-16 81.3cm × 139.7cm (32" × 55")
A: 1.1cm (7/16") B: 1.7cm (11/16") C: 1.9cm (3/4")
Frigidaire
Part # Maximum Frame Size
81-MK514W-9 50.8cm × 76.2cm (20" × 30")
81-MK514W-14 81.3cm × 182.9cm (32" × 72")
81-MK514W-16 81.3cm × 139.7cm (32" × 55")
A: 1.5cm (9/16") B: 1.7cm (11/16") C: 1.9cm (3/4")
Domestic Universal
Part # Maximum Frame Size
81-MK808W-9 50.8cm × 76.2cm (20" × 30")
81-MK808W-14 81.3cm × 182.9cm (32" × 72")
81-MK808W-16 81.3cm × 139.7cm (32" × 55")
A: 1.1cm (7/16") B: 1.7cm (11/16") C: 1.9cm (3/4")
Commercial Universal
Part # Maximum Frame Size
81-MK279G-9 50.8cm × 76.2cm (20" × 30")
81-MK279G-14 81.3cm × 121.9cm (32" × 48")
81-MK279G-18 81.3cm × 182.9cm (32" × 72")
A: 1.9cm (3/4") B: 1.3cm (1/2") C: 2.2cm (7/8")
Commercial Universal
Part # Maximum Frame Size
81-MK026B-9 50.8cm × 76.2cm (20" × 30")
81-MK026B-14 81.3cm × 121.9cm (32" × 48")
81-MK026B-18 81.3cm × 182.9cm (32" × 72")
A: 1.9cm (3/4") B: 1.6cm (5/8") C: 2.5cm (1")
Glaze Port • Habco
Part # Maximum Frame Size
81-MK512B-9 50.8cm × 76.2cm (20" × 30")
81-MK512B-14 81.3cm × 121.9cm (32" × 48")
81-MK512B-18 81.3cm × 182.9cm (32" × 72")
A: 1.1cm (7/16") B: 1cm (3/8") C: 2.2cm (7/8")
Glaze Port
Part # Maximum Frame Size
81-MK573B-9 50.8cm × 76.2cm (20" × 30")
81-MK573B-14 81.3cm × 121.9cm (32" × 48")
81-MK573B-18 81.3cm × 182.9cm (32" × 72")
A: 1.1cm (7/16") B: 1cm (3/8") C: 1.5cm (7/8")
Q.B.D. • Habco • Cornelius
Part # Maximum Frame Size
81-MK548B-9 50.8cm × 76.2cm (20" × 30")
81-MK548B-14 81.3cm × 121.9cm (32" × 48")
81-MK548B-18 81.3cm × 182.9cm (32" × 72")
A: 1.3cm (1/2") B: 1.7cm (11/16") C: 2.4cm (15/16")
M.K.E.
Part # Maximum Frame Size
81-MK2209G-9 50.8cm × 76.2cm (20" × 30")
81-MK2209G-14 81.3cm × 121.9cm (32" × 48")
81-MK2209G-18 81.3cm × 182.9cm (32" × 72")
A: 1.7cm (11/16") B: 1.3cm (1/2") C: 3cm (1-1/16")
81-MK279G-9
Illustrated
Gaskets
