89
Refrigeration
Compression Gaskets
* Extruded
† Note: Bottom flange straightens out to horizontal position when inserted in retainer strip.
Width dimension shown is that when gasket is in assembled position on completed unit.
‡ Note: Cushion height dimension shown is that when gasket is in assembled position on
completed unit.
1/2" Cushion Height
Part #
Material
*
Length
81-A6387-12
Vinyl
12'
81-A6387-100
Vinyl
100'
1/2" Cushion Height
Part #
Material
*
Length
81-A6662-12
Vinyl
12'
81-A6662-100
Vinyl
100'
1/2" Cushion Height
Part #
Material
*
Length
81-6924
Rubber
12'
1/2" Cushion Height
Part #
Material
*
Length
81-P10433
Vinyl
15'
81-P10433-100
Vinyl
100'
1/2" Cushion Height
Part #
Material
*
Length
81-P10441
Vinyl
14'
81-P10441-100
Vinyl
100'
9/16" Cushion Height
Part #
Material
*
Length
81-P1050
Vinyl
14'
81-P1050-100
Vinyl
100'
9/16" Cushion Height
"Roll-In Gasket"
Part #
Material
*
Length
81-P2152-8
†‡
Vinyl
8'
5/8" Cushion Height
Part #
Material
*
Length
81-P10246
Rubber
12'
5/8" Cushion Height
Part #
Material
*
Length
81-P10338
Vinyl
14'
81-P10338-100
Vinyl
100'
5/8" Cushion Height
Part #
Material
*
Length
81-P10427
Vinyl
14'
81-P10427-100
Vinyl
100'
1/4" Cushion Height
Part #
Material
*
Length
81-311
Rubber
12'
5/16" Cushion Height
Part #
Material
*
Length
81-419
Rubber
12'
5/16" Cushion Height
Part #
Material
*
Length
81-1193
Rubber
12'
5/16" Cushion Height
Part #
Material
*
Length
81-997
Rubber
12'
3/8" Cushion Height
Part #
Material
*
Length
81-1788
Rubber
12'
3/8" Cushion Height
Part #
Material
*
Length
81-4868
Vinyl
12'
7/16" Cushion Height
Part #
Material
*
Length
81-2523
Rubber
12'
7/16" Cushion Height
Part #
Material
*
Length
81-A5451-12
Vinyl
12'
81-A5451-100
Vinyl
100'
7/16" Cushion Height
Part #
Material
*
Length
81-P10431
Vinyl
14'
81-P10431-100
Vinyl
100'
1/2" Cushion Height
Part #
Material
*
Length
81-2764
Vinyl
12'
81-2764-100
Vinyl
100'
Applications
• Domestic & Commercial
refrigeration doors
• Vending units
• Dispensers
• Reach-ins
Compression Gaskets
Widely used where an air-tight
seal is needed to keep warm
and cold temperatures separate.
Notice
• When determining the cushion height for
your application, the gasket cushion should
be compressed a minimum of 1/8" (0.3cm)
to a maximum of 3/16" (0.5cm) to obtain
the most efficient seal.
• Food containers
• Sound barriers
• Bumper strips
• Dust seals
• Thermal insulation
Gaskets
