Trade Line Gauges
Trade Line Gauges
Weiss TL gauges are intended
for general service conditions, for
pressure or vacuum on air, oil,
water, gas or other mediums that
do not attack brass. TL gauges
are furnished in drawn steel cases,
finished in black. The 1 1/2" dials
are supplied with 1/8" NPT and 2"
dial versions are available with 1/4"
or 1/8" NPT connections. All other
dial sizes are 1/4" NPT. All gauges
conform with ANSI B40.1 accuracy
Grade B-2% mid scale.
14-TL45-200
Illustrated
14-TL20-100
Illustrated
1 1⁄2" Dial
• 1/8" NPT Back Connection
Part # Range
14-TL15B-030 0 to 30 PSI
14-TL15B-060 0 to 60 PSI
14-TL15B-100 0 to 100 PSI
14-TL15B-160 0 to 160 PSI
14-TL15B-200 0 to 200 PSI
2" Dial
• 1/8" NPT Back Connection
Part # Range
14-TL28-015 0 to 15 PSI
14-TL28-030 0 to 30 PSI
14-TL28-060 0 to 60 PSI
14-TL28-100 0 to 100 PSI
14-TL28-160 0 to 160 PSI
14-TL28-200 0 to 200 PSI
14-TL28-300 0 to 300 PSI
14-TL28-VAC 0 to 30" HG VAC
14-TL20-V60 30 to 0 to 60 PSI
14-TL20-V150 30 to 0 to 150 PSI
3 1⁄2" Dial
• 1/4" NPT Lower Connection
Part # Range
14-TL35-015 0 to 15 PSI
14-TL35-030 0 to 30 PSI
14-TL35-060 0 to 60 PSI
14-TL35-100 0 to 100 PSI
14-TL35-160 0 to 160 PSI
14-TL35-200 0 to 200 PSI
14-TL35-300 0 to 300 PSI
14-TL35-400 0 to 400 PSI
14-TL35-VAC 0 to 30" HG VAC
14-TL35-V30 30 to 0 to 30 PSI
14-TL35-V60 30 to 0 to 60 PSI
14-TL35-V100 30 to 0 to 100 PSI
14-TL35-V150 30 to 0 to 150 PSI
4 1⁄2" Dial
• 1/4" NPT Lower Connection
Part # Range Part # Range
14-TL45-015 0 to 15 PSI 14-TL45-300 0 to 300 PSI
14-TL45-030 0 to 30 PSI 14-TL45-VAC 0 to 30" HG VAC
14-TL45-060 0 to 60 PSI 14-TL45-V30 30 to 0 to 30 PSI
14-TL45-100 0 to 100 PSI 14-TL45-V60 30 to 0 to 60 PSI
14-TL45-160 0 to 160 PSI 14-TL45-V100 30 to 0 to 100 PSI
14-TL45-200 0 to 200 PSI 14-TL45-V150 30 to 0 to 150 PSI
