Single Groove Sheaves - Type 67-AKH
Single Groove Sheaves - Type 67-BKH
Type 2
Type 3
Type 1
Stock "QG" Bushings
Type 67-AKH Single Groove Sheaves
Part #
Diameters
Type Bush
Dimensions
Stock
QH
Bores
Outside DD
"A"
Pitch
"3L"
F X C
67-AK30H
3.05 2.80 2.46
1 QH 3/4 – 1 13/16
3/8
67-AK32H
3.25 3.00 2.66
7/16
67-AK34H
3.45 3.20 2.86
2 QH 3/4 – 7/8
1/2
67-AK39H
3.75 3.50 3.16
9/16
67-AK41H
3.95 3.70 3.36
5/8
67-AK44H
4.25 4.00 3.66
11/16
67-AK46H
4.45 4.20 3.86
3/4
67-AK49H
4.75 4.50 4.16
13/16
67-AK51H
4.95 4.70 4.36
7/8
67-AK54H
5.25 5.00 4.66
15/16
67-AK56H
5.45 5.20 4.86
1
67-AK59H
5.75 5.50 5.16
67-AK61H
5.95 5.70 5.36
3 QH 3/4 0 7/8
1 1/8
67-AK64H
6.25 6.00 5.66
1 3/16
67-AK66H
6.45 6.20 5.86
1 1/4
67-AK69H
6.75 6.50 6.16
67-AK71H
6.95 6.70 6.36
1 3/8
67-AK74H
7.25 7.00 6.66
67-AK79H
7.75 7.50 7.16
67-AK84H
8.25 8.00 7.66
Type 67-BKH Single Groove Sheaves
Part #
Diameters
Type Bush
Dimensions
Outside DD
"A"
Pitch
"3L"
F C X
67-BK30H
3.15 2.40 2.80
1 QH 7/8 – 1 5/16
67-BK32H
3.35 2.60 3.00
67-BK34H
3.55 2.80 3.20
67-BK36H
3.75 3.00 3.40
2 QH 7/8 – 7/8
67-BK40H
3.95 3.20 3.60
67-BK45H
4.25 3.50 3.90
67-BK47H
4.45 3.70 4.10
67-BK50H
4.75 4.00 4.40
67-BK52H
4.95 4.20 4.60
67-BK55H
5.25 4.50 4.90
67-BK57H
5.45 4.70 5.10
67-BK60H
5.75 5.00 5.40
67-BK62H
5.95 5.20 5.60
67-BK65H
6.25 5.50 5.90
67-BK67H
6.45 5.70 6.10
67-BK70H
6.75 6.00 6.40
3 QH 7/8 1/16 7/8
67-BK72H
6.95 6.20 6.60
67-BK75H
7.25 6.50 6.90
67-BK77H
7.45 6.70 7.10
67-BK80H
7.75 7.00 7.40
67-BK85H
8.25 7.50 7.90
67-BK90H
8.75 8.00 8.40
67-BK95H
9.25 8.50 8.90
67-BK100H
9.75 9.00 9.40
67-BK105H
10.25 9.50 9.90
Type 67-AKH
• Single Groove Sheaves for "4L" or "A" Belts .
• "3L" Belts may be used with these sheaves as
indicated in table below.
• Stock sizes - With split taper bushings.
Type 67-BKH
• Single groove sheaves - combination groove
for "4L" or "A" belts and "5L" or "B" belts
stock sizes - with split taper bushings.
Type 2
Type 3
Type 1
67-AK30H
Illustrated
67-BK30H
Illustrated
