Butt’s Pumps and Motors - page 1124

119
Heating & A/C
Beckett’s High Efficiency PSC Motor
Based on proven durability of the AFII motor
after 10 years of high reliability in the field.
• Lower amp draw
• Cooler operation
• Fewer failures
• Delivers more power
• Ball bearings for longer life
• 5 year warranty.
Universal High Efficiency PSC Motor
Part #
HP RPM Volts Rotation Type
T4-R21805U
1/7 3450 120V CCW PSC.
Beckett CleanCut Pump
•Smoother, cleaner shut-downs & light-off.
• Fewer moving parts and troublesome oil fittings to cause problems.
• Reduced load on motor.
• Higher capacity - up to 4 gph at 150-200 psi.
• Same piston valve used in traditional pumps, to provide the same level of
protection from leak-through in gravity feed situations.
• Beckett PD (precision delay timer) - a precise valve-on 4-second delay, virtually
unaffected by temperature or voltage which eliminates the need for a pre-purge
control.
Beckett Oil Burner Controls
Standard Features: (B1032)
• Interrupted Ignition
• Limited Recycle
• Limited Reset
• Communications Port
• Diagnostic LED
• Ambient Range (-40°F to 147°F)
• 15 Second Pre-Purge
Universal Electronic Oil Igniter Kit
Part #
Description
65-51846
Kit Includes Igniters For:
• Aero
• Beckett (A, AF, AFG & S)
• Carlin (100)
R7184 Controls
Part #
Reference
65-7455U
R7184A-1075
65-7456U
R7184B-1032
65-7457U
R7184P-1064
65-7458U
R7184P-1072
Beckett’s Clean-Cut Pump
Part #
Description
65-2184404
Oil pump with precision delay timer.
Oil Burner Igniter Kit
Oil Burner Controls
Oil Burner Pump
Oil Burner Motor
Universal Electronic Oil Igniter Kit
Entire kit weighs less than one standard transformer. Equipped with two
igniters, various terminals, detailed installation instructions and assorted
mounting plates makes this one little kit capable of adapting to numerous
furnace makes & models.
Universal Replacement
For Emerson, GE, A.O
Smith & Marathon.
65-51846
Illustrated
65-7455U
Illustrated
65-2184404
Illustrated
T4-R21805U
Illustrated
Oil Igniters
