"Pro" Ignition Repair Kit
This kit contains a variety of ignition terminals, standard electrodes,
popular OEM electrodes and other necessary accessories to get
burners up and running. Don't leave the shop without it!
Electrode Ignition Repair Kit
Electrode Roll-Up Repair Kits
"Mechanic" Electrode Roll-Up Kit
This kit contains 8 different standard and 2 popular
OEM electrode assembly designs. It also comes
with 10 of the most universal insulators in the oil heat
industry to restore service due to electrode or insulator
failure.
"Mechanic" Electrode Roll-Up Kit
Part # Description
60-40277
Kit Includes:
Standard Electrodes
(2) 60-05040
(2) 60-05050
(2) 60-05060
(2) 60-06050
OEM Electrodes
(2) 60-27030 Quiet Heat
Insulators
60-11041
60-15040
60-15050
60-15060
60-16050
"Pro" Ignition Repair Kit
Part # Description
60-40275
Kit Includes:
Standard
Electrodes
(4) 60-01041
(2) 60-03050
(2) 60-04040
(4) 60-05040
(4) 60-05050
(2) 60-05060
(2) 60-06040
(2) 60-06042
(2) 60-06050
(2) 60-06060
OEM Electrodes
(2) 60-20410 Beckett
(2) 60-20780 Carlin
(2) 60-28022 Wayne
Buss Bars
(2) 64-40315 12"
round buss bar.
(2) 64-40320 12"
flat buss bar.
Terminals & Hardware
(10) 64-50000 Cage terminals.
(10) 64-50100 Spring terminals.
(10) 64-50200 Ring terminals.
(10) 64-50450 Right angle cage terminals.
(10) 64-50600 Stud ferrule.
(10) 64-50760 Hex base stud 6-32 threads.
(10) 64-50700 Hex base stud 10-32 threads.
(10) 64-50860 Hollow stud 6-32 threads.
(10) 64-50800 Hollow stud 10-32 threads.
(10) 64-50900 Eyelets.
(10) 64-60018 Flat hex nut 6-32 threads.
(10) 64-60022 Flat hex nub 10-32 threads.
Special Tools
(1) 12-40430 Igniter tip bending set.
(1) 12-40445 Electrode setting gauge.
(1) 12-40630 Booted test leads set.
(1) 5' length GTO-15 ignition cable.
(1) Trouble shooting chart.
60-40275
Illustrated
60-40277
Illustrated
Electrodes
