Butt’s Pumps and Motors - page 1126

121 Heating & A/C www.alltemp.ca
Notes:
• Longer insulator lengths available upon request.
• Tips can be supplied straight and in standard length of 3".
• Longer lengths can be supplied upon request.
• Add the letter S, after the electrode part number, when
ordering the straight electrode.
• Insulators packaged 2, 10 or 25 to a box. Add a — (dash)
and the number 2, 10 or 25 to insulator part # when
ordering insulators.
Standard Electrodes
3/16" Dia.
3/16" Dia.
Standard Electrodes
9/16" dia. insulator, 3/16" dia. electrode.
Electrode
Part #
Insulator
Only Part #
Insulator
Length
Type of
Tip
60-05030 60-15030 3"
Light
3/32" dia.
60-05033 60-15033 33⁄4"
60-05040 60-15040 4"
60-05042 60-15042 41⁄2"
60-05050 60-15050 5"
60-05052 60-15052 51⁄2"
60-05060 60-15060 6"
60-05070 60-15070 7"
Add an "S" after part # when ordering straight tip electrodes.
Standard Electrodes
9/16" dia. insulator, 3/16" dia. electrode.
Electrode
Part #
Insulator
Only Part #
Insulator
Length
Type of
Tip
60-06040 60-16040 4"
Light
3/32" dia.
60-06042 60-16042 41⁄2"
60-06050 60-16050 5"
60-06060 60-16060 6"
60-06070 60-16070 7"
Add an "S" after part # when ordering straight tip electrodes.
Standard Electrodes
1/2" dia. insulator, 3/16" dia. electrode.
Electrode
Part #
Insulator
Only Part #
Insulator
Length
Type of
Tip
60-09940 60-19040 4"
Light
3/32" dia
60-09042 60-19042 41⁄2"
60-09050 60-19050 5"
60-09060 60-19060 6"
60-09070 60-19070 7"
60-09080 60-19080 8"
Add an "S" after part # when ordering straight tip electrodes.
For Assistance Replacing An OEM Specific Electrode -sales@alltemp.ca
9/16"
9/16" 3/16" Dia.
1/2"
Insulator Only
1 1/8"
2 11/16"
45°
Electrodes
