130
Heating & A/C
Terminal Connectors
64-50000
Cage
64-50100
Spring
64-50200
Ring
64-50250
Hook
64-50400
Angle cage
64-50450
Right angle cage
64-50500
Angle spring
64-50600
Stud ferrule
64-55011
Stud/angle nylon
cap
64-55021
Base stud/solderless
brass ferrule
64-55101
Solderless ring
64-55201
Solderless spring
64-55211
Spring/angle nylon cap
64-55221
Spring/solderless
brass ferrule
64-55001
Hex Base Stud/
Short Nylon
Observation Ports
Observation Ports
Unsurpassed quality! These ports offer unitized cico-weld construction
with non-organic gasket in four standard sizes: from 3/8" to 1"
diameter. The one piece design is compact and leakproof at high
temperatures and pressures. Maximum operating temperature is rated
at 400°F.
Observation Ports
Include gaskets.
Part # Hex Size Threads
Viewing
Area
Maximum
Operating
Pressure
60-P-38
3/4"
3/8"-18 7/16"
350 psi
60-P-50
7/8"
1/2"-14 5/8"
275 psi
60-P-75
1 1/8"
3/4"-14 3/4"
200 psi
60-P-100
1 3/8"
1"-11.5 1"
150 psi
60-P-38
Illustrated
64-50760
6 - 32
64-52266
8 - 32
64-50700
10 - 32
Hex base stud
64-50761
6 - 32
64-50751
10 - 32
Long hex base stud
64-50850
5 - 40
64-50860
6 - 32
64-50880
8 - 32
64-50800
10 - 32
Hollow thread stud
Applications
• Burner face plates
• Boiler ports
• Magnetic separators
• Gas generators
• Hermetic compressors
Terminal Connectors
