Butt’s Pumps and Motors - page 1130

125 Heating & A/C www.alltemp.ca
Beckett Electrode Tune Up Kit
Part # Description Models
60-5780C
Kit Includes:
(2) Electrode assemblies.
(2) Bullet connector studs.
(2) Extension rods.
(2) 10-32 hex nuts.
(1) Instruction sheets.
AFG, AF, AR, SF & SR burners up
to 9" air tube combinations.*
60-5780K
Kit Includes:
(2) Electrode assemblies w/connector studs.
(2) Extension rods.
(2) 10-32 hex nuts.
(1) Instruction sheets.
(1) KK100 coupler w/ end caps.
(1) 12" × 3/16" dia copper oil line.
AF, AR, SF & SR burners up to 9"
air tube combinations.*
60-5781
Kit Includes:
(2) Electrode assemblies.
(2) Bullet connector studs.
(2) Spring connectors
(2) Extension rods.
(2) 10-32 hex nuts.
(1) Instruction sheets.
A & S burners up to 9" air tube
combinations.
60-5782C
Kit Includes:
(2) Electrode assemblies.
(2) Secondary support insulators.
(2) Bullet connector studs.
(2) Extension rods.
(2) 10-32 hex nuts.
(1) Instruction sheets.
AFG, AF, AR, SF & SR burners
over 9" air tube combinations.*
60-5782K
Kit Includes:
(2) Electrode assemblies w/connector studs.
(2) Secondary support insulators.
(2) Extension rods.
(2) 10-32 hex nuts.
(1) Instruction sheets.
(1) KK100 coupler w/ end caps.
(1) 12" × 3/16" dia copper oil line.
AFG, AF, AR, SF & SR burners
over 9" air tube combinations.*
60-5783
Kit Includes:
(2) Electrode assemblies.
(2) Secondary support insulators.
(2) Bullet connector studs.
(2) Spring connectors
(2) Extension rods.
(2) 10-32 hex nuts.
(1) Instruction sheets.
A & S burners over 9" air tube
combinations.
60-51484U
Kit Includes:
(2) Electrode assemblies.
(2) Transformer wires.
(1) Multi-purpose setting gauge.
(1) Instruction sheets.
AFII-85 & AFII-150 with air tube
combination models HLX - HB,
HC, HD & HE up to 9" air tube
combinations.
*Setting gauge sold separately (60-40443).
Beckett Electrode Tune Up Kits
60-5780C
Illustrated
60-5780K
Illustrated
60-5781
Illustrated
60-5782C
Illustrated
60-5782K
Illustrated
60-5783
Illustrated
60-51484U
Illustrated
Electrodes
