Service Tools
Flaring & Swaging Tools
Part #
Description
46-FT195
45° Flaring Tool
• 3/16", 1/4", 5/16", 3/8", 1/2" & 5/8" O.D. tubing.
46-FS275
Premium 45° Flaring & Swaging Tool Kit
• 1/8",3/16", 1/4", 5/16", 3/8", 7/16", 1/2", 5/8" & 3/4"
O.D. tubing.
46-FT500
Flares & Burnishes
• 3/16", 1/4", 5/16", 3/8", 1/2" & 5/8" O.D. tubing.
46-FT525
Universal Flaring & Burnishing Tool
• Any size tubing from 3/16" to 5/8" O.D. tubing.
46-BTQ180
Flaring tool clutch type R410A.
46-BTQ420
Flaring tool gauge.
Replacement Parts & Accessories
Part #
Description
Part #
Description
46-FS226
Tube cutting, double flaring kit 1/8" to 3/4".
46-FSX504
1/8", 3/16", 1/4", 3/8" swaging adap. 46-FS275.
46-FS275M
45° flaring, swaging kit 4mm to 22mm.
46-FSX505
1/2" swaging adapter for 46-FS275.
46-FS276M
ISO Metric bubble flaring tool kit 4.75, 6, 8, 10.
46-FSX506
5/8" swaging adapter.
46-FTX500
Yoke assembly for 46-FT195.
46-FSX508
3/4" swaging adapter.
46-7885801
Yoke assembly for 46-FS275 (cone excluded).
46-FSX507
8, 12, 14, 16, 22mm swaging adapter.
46-FTX513
Yoke assembly for 46-FT500.
46-FSX501
7/16", 1/4", 1/8", 3/16", 5/16", 3/8" bar.
46-FTX516
Yoke assembly for 46-FT525.
46-FSX502
1/2", 5/8", 3/4" O.D. short bar.
46-38600
Cone for 46-FS275.
46-FT500M
45° flaring, burnishing tool 6mm to 16mm.
46-FTX518
Cone for 46-FT525.
46-FTX501
3/16", 1/4", 5/16", 3/8", 7/16", 1/2", 5/8" flare bar.
46-FTX509
Compressor cone.
46-FSX511
4, 6, 8, 10, 12, 15, 16mm flaring bar.
46-FT806A
1/4", 5/16", 3/8", 1/2", 5/8", 3/4" eccentric cone flaring tool.
46-FSX512
14, 18, 22mm flaring bar.
46-FT806M
6, 8, 10, 12, 15, 16, 18mm eccentric cone flaring tool.
46-FTX514
Die holder assembly for 46-FT500.
46-FTX510
Wing nut.
46-FTX515
Die holder assembly for 46-FT500.
46-FSX503
5/16" swaging adapter for 46-FS275.
46-FTX517
Tube holding assembly for 46-FT525.
Flaring & Swaging Tools
• For soft tubing - copper, aluminum, brass.
• Lifetime warranty.
Flaring Tools
LIFETIME WARRANTY!
On CPS Flaring Tools
46-FT195
Illustrated
46-FT525
Illustrated
46-FT500
Illustrated
46-FS275
Illustrated
46-BTQ180
Illustrated
R410A
Compatible
Flaring Tools
