264
Service Tools
R12 Adapter Kit
Part #
Description
46-ADK12
Kit Contains:
• Shut off ball valves for A/C hoses.
• Quick disconnects.
• Straight adapters plus 1/8" and 3/16" systems that still require
Freon recovery.
Adapters sold separately: AD18C, AD48, ADGM, BV, BV90, BVAD90, QCFD, QCGM.
Automotive Adapter Kits
R134a To R12 Adapter Kit
Use your R134a manifold to check old R12 systems.
Part #
Description
46-ADK1234
Flex Hoses
46-HT134L 1⁄4" SAE × R134a low (blue).
46-HT134H 3/16" SAE × R134a high (red).
Tanks
46-AD12 1⁄2" acme female × R134a high.
Straight
46-AD48 1⁄4" SAE female × 1⁄2" acme male.
R12 To R134a Adapter Kit
Retrofit R12 tools to R134a for vacuum and recharging with the
46-ADK134 kit.
Part #
Description
46-ADK134
Couplers 46-QCH14 & 46-QCL14 1⁄4" SAE.
Can Tap 46-TLCT134 1⁄2" acme female × 1⁄2" acme male.
Tanks
46-AD12 1⁄2" acme × low.
Pumps
46-AD48 1⁄4" SAE female × 1⁄2" acme male.
46-AD84 1⁄2" acme female × 1⁄4" SAE male.
46-ADK12
Illustrated
46-ADK1234
Illustrated
46-ADK134
Illustrated
Use your
R134a manifold
to check old
R12 systems.
Retrofit R12
tools to
R134a for
vacuum and
recharging
with this kit.
Automotive
Automotive
Automotive
"T" Ball Valve Service Port
"T" Ball Valve Service Port For R12 & R134a Systems
Air conditioning mechanics are always having to connect and disconnect to the
system to perform recovery, evacuation, charging, checking vacuum, adding oil
and injecting dye or sealant. The 20-ET14 "T" connector provides an isolated
port for easy access to the system while minimizing any risk of air entering
the system. The three ball valve system allows 3-position isolation therefore
providing the mechanic total flexibility to install products at the vehicle rather
than contaminating hoses. One connects from the recovery machine providing
high or low side adapters while the second port connects to the high side of the
vehicle with a short hose. The third port remains open to use as an optional
service port.
"T" Ball Valve Service Port
Part #
Description
20-ET14134
Automotive "T" service port kit, includes
20-ET14 "T" connector, high & low side
fittings, couplers & service hose.
20-ET14
Ball valve isolated service "T" only.
20-ET14134
Kit
20-ET14
"T" Only
Fittings & Adapters
