276
Service Tools
02-CD3800
Illustrated
Adjustable Torque Wrench
Features
Rotary torque mechanism prevents over-torquing
of valve core. Wrench is easily adjustable from 1 to
6"/lbs. in 0.05 increments. A locking ring prevents
accidental alteration of the torque setting. Accuracy
±3% at each increment. Standards of accuracy
exceed those of the National Institute of Standards
and Technology. Certification available upon request.
12-32002
Illustrated
Adjustable Torque Wrench
Part #
Description
12-32002
Used to tighten valve cores to the proper torque. Recommended
torque range is 11⁄2" to 3"/lbs. Over tightening of a valve core can
cause damage to the core and loss of refrigerant.
12-32003
Bit designed specifically for use with valve cores.
Instructions
• Turn black ring to
unlock internal
mechanism.
• Adjust torque to
desired setting.
• Return black ring
to locked position.
Core Container Wrench
Part #
Description
02-CD3813
• Durable construction.
• Core container with wrench.
• All brass with knurl for easy handling.
• Compact design holds three valve cores.
02-CD3813
Illustrated
Core Removal Tools
1/4" Valve Core Tool
Part #
Description
Package
02-C32004
• 1/4" valve core tool.
• Hollow handle for storage.
• Furnished with 6 extra cores.
1/pk
02-C32004-147
• Replacement core remover bits for old
style.
2/pk
Fitting Caps + Core Remover
Part #
Description
Package
02-C31997
• 1/4" SAE gasket seal cap with core remover.
5/pk
02-CD2250
• 1/4" flare heavy-duty brass cap with core remover
tool and neoprene o-ring seal.
6/pk
02-C31998
• 1/4" Standard core remover.
5/pk
02-C31997
Illustrated
02-C31998
Illustrated
02-CD2250
Illustrated
02-C32004
Illustrated
Core Chaser & Wrench
Part #
Description
02-CD3800
• Two tools in one.
• Core wrench and a thread chaser.
• Storage bottle for cores.
• Comes with six (6) cores.
• 31⁄2" overall length.
Core Removal Tools
