272
Service Tools
Telescoping Inspection Glass Mirrors
• All models are made of stainless steel with brass
backed mirrors.
Part #
Description
46-TLMIR1
(1 1⁄4") diameter circular telescoping pocket mirror.
46-TLMIR2
(2 1⁄4") diameter circular telescoping mirror.
46-TLMIR3
(2 1/8" × 3 1⁄2") Rectangular telescoping mirror.
46-TLMIR4
(1" × 2") oval pocket mirror.
Inspection Mirrors
12-TLMIR1
Pocket
12-TLMIR2
Round
12-TLMIR3
Large
12-TLMIR4
Pocket
Telescoping Inspection Steel Mirrors
• Unbreakable, made of highly polished stainless steel
Part #
Description
12-7500
Small (2" × 11⁄4") rectangular mirror.
12-7300
Large (2" × 33⁄4") rectangular mirror.
12-7400
Large round (33⁄4") mirror.
Inspection Mirror Replacement Parts
• For 12-7500, 7300 & 7400 series inspection mirrors.
Part #
Description
12-7500-1
Small (2" × 11⁄4") rectangular spare mirror only.
12-7500-2
Small (2" × 11⁄4") rectangular spare mirror & swivel.
12-7300-1
Large (2" × 33⁄4") rectangular spare mirror only.
12-7300-2
Large (2" × 33⁄4") rectangular spare mirror & swivel.
12-7400-1
Large round (33⁄4") spare mirror only.
12-7400-2
Large round (33⁄4") spare mirror & swivel.
12-7303
Telescopic handle.
12-7304
Swivel link assembly.
12-7300
Large
12-7500
Small
12-7400
Round
Telescoping Magnets- Alltemp
Part #
Description
12-EM18
18" telescoping extension magnet.
12-EL26
26" telescoping extension lighter.
Magnet & Lighter Extension Instruments
12-EM18
Round
12-EL26
Round
Tube Piercing Pliers
Recover refrigerant quickly with clamp on, tube
piercing pliers. Pliers are simple to use and light
weight. Piercing tip easily replaceable.
Part #
Description
46-TLPP
Tube piercing pliers (Vise Grip®).
Works on tubing sizes from 1/4" to 7/8".
46-TLPPX
Replacement tip for 46-TLPP
Tube Piercing Pliers
Instructions
Connect service hose to fitting on pliers. Size locking pliers to tubing for proper
clamping. Align tip to centre of tubing and clamp down. Recover refrigerant.
46-TLPPX
Illustrated
46-TLPP
Illustrated
Glass
Steel
Inspection Mirrors
