260
Service Tools
R12 to R134a Hose Conversion Sets
Part #
Description
46-HC6
Complete manifold hose set 1/4" SAE ×
1/2" Acme 6' hoses with R134a couplers.
46-HC6B
Blue replacement hose.
46-HC6R
Red replacement hose.
46-HC6Y
Yellow replacement hose.
46-QCL134
R134a low coupler 14mm.
46-QCH134
R134a high coupler 14mm.
R12 & R134a Flex Hose Adapters
Part #
Description
46-ADK237
R12 Flex hose kit (not shown).
46-HTAD1
R12 1/4" × 1/4" SAE.
46-HTAD2
R12 1/8" × 1/4" SAE.
46-HTAD3
3/16" × 1/4" SAE.
46-HT134L
1/4" SAE × R134a low.
46-HT134H
3/16" SAE × R134a high.
R12 to R134a Automotive Hose Conversion Set
R12 & R134a Automotive Flex Hose Adapters
46-HC6
Illustrated
Automotive
Automotive
Replacement Parts - Charging Hoses
Part #
Description
46-HXGD
(6) 1⁄4" SAE hose gaskets & (6) core depressors.
46-HX3G
(10) 3/16" hose gaskets.
46-HX14R
(10) 14mm hose rings.
46-HX38G
(10) 3/8" hose gaskets.
46-HXG
(10) hose gaskets - fits 1⁄4" SAE & 1⁄2" Acme.
46-HXD
(10) 1⁄4" SAE hose core depressors.
46-HX4D
(10) 1⁄4" SAE top hat core depressors.
Charging Hoses - Replacement Parts
46-HXD
Illustrated
46-HXG
Illustrated
R134a Recharge Hose Kit
Part #
Description
46-HT134
Screws onto 12 oz. can for low side
charging. Works on 1/2" Acme cans
only.
R134a Recharge Hose Kit
46-HT134
Illustrated
Automotive
Hose Service Kit
This assortment contains hose gaskets, valve cores,
service port caps and coupler o-rings. Order the 46-
HXKIT for both R134a and R12. Replacement parts
sold individually include: 46-AVS1, AVC3P, AVC4P,
AVC134L, AVC134H, HXD, HX3D, HX4D, HXG,
HX14R, QCXR34.
Part #
Description
46-HXKIT
R134a & R12 hose service kit.
R134a & R12 Automotive Charging Hoses Service Kit
46-HXKIT
Illustrated
Automotive
Charging Hoses
