Butt’s Pumps and Motors - page 1310

305 Service Tools www.alltemp.ca
Digital Temperature Humidity Tester
Part # Specifications
14-RHT-1
Electrical
• Display: 3 1/2" digit, 1/2" LCD display.
• Range
Humidity: 10% - 95% RH.
Temperature: -20 to 140°F (-30 to 60°C).
• Resolution: 0.1% RH, 0.1°C, 0.1°F.
• Accuracy
Humidity: 2% RH @ 25°C, 30 - 95% RH.
5% RH @ 25°C, 10 - 30% RH.
• Temperature: ±0.8°C (±1.0°F).
• Sensor Type
Humidity: precision gold capacitance sensor.
Temperature: semiconductor sensor.
• Response Time
Humidity: 45% - 95% < 3 minutes.
95% - 45% < 5 minutes.
Temperature: 1°C / 2 seconds.
• Sampling Rate: 2.5 times per second.
• Auxiliary Outputs
Humidity:10mVdc/ 1% RH.
Temperature: 10mVdc/ 1°C
Environmental
Operating Temperature: 0 to 50°C (32 to 122°F*).
*(-20 to 140°F will operate for limited time period).
Operating Humidity: >85% RH
Storage Temperature: -10 to 60°C (14 to 140°F)
Storage Humidity: > 70% RH
Temperature Humidity Tester
Accurate humidity measurement at reasonable cost with usable functions best describes the Weiss 14-RHT-1.
This rugged hand held instrument features a wide humidity measurement range from 10% to 95% and a
temperature range from -4° to 140°F (-20° to 60°C). Accuracy of 2% RH and 1°F, plus a F/C switch, Hold feature
and Output Jack make the 14-RHT-1 ideal for HVAC and refrigeration applications. The precision capacitance
humidity sensor offers fast response and the output jack offers the ability to record data or remotely monitor
both temperature and humidity. These features are normally found on instruments costing much more than the
reasonably priced 14-RHT-1, complete with 400 hour 9V battery and case.
HT2096 Series Thermo/ Hygrometer
• Temperature & humidity indicator.
• Desktop or wall mounted.
• Compact design.
Part # Specifications
14-HT-2096C • 40/0/70°C (15% to 95% RH)
14-HT-2096 • 40/0/122°F (15% to 95% RH)
14-HT-2096FB* • 40/0/122°F (15% to 95% RH)
* Unit is encased in an attractive brass face plate.
Digital Temperature & Humidity Indicator
Digital Temperature Humidity Tester
14-RHT-1
Illustrated
Standard Packaging
14-HT2096
Illustrated
Humidity Testers
