306 Service Tools www.alltemp.ca
Digital Thermo-Anemometer
Part # Features Specifications
14-CFM-01
• CFM made easy.
• Large LCD.
• Dual display.
• °C or °F.
• Auto shut-off.
• 9V battery included.
• Comes with carrying case.
• Display: 1/2" with 3/8" digit.
• Bearing: Sapphire jewel bearing.
• Operating Temperature:
- Meter: 0° to 50°C (32° to 122°F).
- Vane: 0° to 60°C (32° to 140°F).
• Operating Humidity: Less than 80% RH.
Digital Thermo-Anemometer
The 14-CFM-01 is a valuable tool in the measurement of air flow and air
temperature. This instrument will automatically calculate CFM's and CMM
(cubic ft. per minute & cubic meters per minute). Instant/ average and 2/3V
max flow measurements are simply and easily obtained using the 12 key pads
to enter the duct or hood area in feet or meters and displayed on the LCD dual
readout. Air velocity can be measured in m/s, ft./min, knots, km/hr. and mph.
Temperature readings are obtained with fast response type K thermocouple.
Range Of Wind Velocity
Units Range Resolution Accuracy
m/s 0.0 to 45.0 0.1 ±3% ±0.1
ft/min 0.0 to 8800 0.1/ 1 ±3% ±10
knots 0.0 to 88.0 0.1 ±3% ±0.1
km/hr 0.0 to 140.0 0.1 ±3% ±0.1
mph 0.0 to 100.0 0.1 ±3% ±0.1
Digital Thermo-Anemometer
Range Of Wind Temperature
Units Range Resolution Accuracy
°C 0.0 to 45.0 0.2 ±1.0°C
°F 32.0 to 113.0 0.36 ±1.8°F
14-CFM-01
Illustrated
Air Velocity Meter
Part # Specifications
46-AM50
Range
• 0 to 8,800 ft/min.
• 0 to 45 m/s.
• 0 to 140 km/hr.
• 0 to 88 knots.
Accuracy
• ±3% or 0.1
• ±3% or 0.1
• ±3% or 0.1
• ±3% or 0.1
Air Velocity Meter
Precision vane type anemometer provides fast, accurate air
velocity measurements for use in balancing HVAC systems
or determining CFM calculations. A convenient type "K"
thermocouple is built-in to the remote van providing quick
measurement of grille or duct outflow temperatures from
0°C to 50°C (32°F to 122°F). Included, is an easy-to-read
laminated conversion chart that allows the user to quickly
convert air velocity measurements into CFM calculations at a
glance. and a rugged carrying case.
Digital Thermo-Anemometer
46-AM50
Illustrated
Anemometers
