308
Service Tools
84-HF1-12
Illustrated
Handi-Foam® One-Component Foam
It can be used to economically insulate, seal, bond, fill and stop air infiltration.
One-component foams cure when moisture in the air reacts with the chemistry
of the foam. All one-component foams meet ASTM E-84 flame spread
requirements for caulks and sealants. Handi-Foam One-Component Foam is
tack-free in less than 10 minutes and cures within 24 hours. Handi-Foam One-
Component Foams cure to in-place densities between 1.0 and 2.0 lb. per cubic
foot (16.02 to 32.04 kg. per cubic meter) and carry an R-value of 4 to 5 per inch
(0.03 w/m.k). Cured foam can be trimmed, sanded and/or painted.
Applications
• Filling cracks and voids
• Sealing around HVAC units
• Filling gaps around pipes
• Filling gaps behind electrical outlets
• Sealing cracks at wall and floor joints
• Fixing small holes and other damage
Handi-Foam® Straw Foam
• Handi-Foam Straw Foam with non-flammable propellant/ blowing agent.
• Consists of a canister and one-piece straw applicator.
• Lightweight cans are ideal for small projects.
Part #
Description
Weight
84-HF1-12
Straw Foam 12oz. (340g)
1.17 lb (0.53 kg)
84-HF1-24
Straw Foam 24oz. (680g)
2.0 lb (0.91 kg)
84-HF1-33
Straw Foam 33oz. (935g)
2.58 lb (1.17 kg)
Insulation Spray Foam (One-Component)
Handi-Foam® Gun Foams
• Consists of a single canister and is applied with a dispensing unit.
• Provides increased control and metering.
• Reduces waste and saves time.
• Handi-Foam Gun Foam with non-flammable propellant /blowing agent.
Part #
Description
Weight
84-P10115
Gun Foam 24oz. (680g)
2.0 lb (0.53 kg)
84-P10290
Gun Foam 31oz. (880g)
2.42 lb (0.55 kg)
84-P10295
Gun Foam (Black) 31oz. (880g) 2.42 lb (0.55 kg)
84-P10115
Illustrated
Handi-Foam® One-Component Cylinders
• Consists of a single canister ordered with or without hoses and
applicators.
• Provides the most efficient application for large projects.
• Cylinder foam is often chosen by professionals over straw or gun foam.
• Handi-Foam® Cylinder Foam with non-flammable propellant/ blowing
agent.
Part #
Description
Weight
84-P10340
160 Handi-Foam® with Accessories 16lbs (7.26kg)/ unit
84-P10341
160 Handi-Foam® without Accessories 15lbs (6.80kg)/ unit
84-P10540
260 Handi-Foam® with Accessories 24lbs (10.89kg)/ unit
84-P10541
260 Handi-Foam® without Accessories 23lbs (10.43kg)/ unit
84-P10340
&
84-P10540
Illustrated
Spray Foam
