307
Service Tools
Clamp-On AMP-SEEKER® Replacement Parts
Part #
Description
Part #
Description
46-ACXB4
Batteries (2) 1.55V (46-AC400).
46-ACXP
Probe set (46-AC600 & 46-AC610).
46-ACXC6
Carrying case (46-AC600 & 46-AC610).
46-ACXTP
Temperature probe (46-AC600).
46-ACXF60
Fuse (46-AC600)
46-ACXOP
Ohms probe.
Electrical Test Instruments
Mini Clamp-On Amp-seeker®
Pocket sized auto ranging clamp-on meter measuring ACA, ACV and continuity.
Large 1⁄2" x 31⁄2" digit (1999 count) LCD display with low battery and data hold
indicators. Unit includes probe set and batteries. Protected to a maximum of
800 Vrms/ 500Arms.
Mini Clamp-On Amp-seeker®
Part #
Features
Specifications
46-AC400
Function
• VAC
• ACA
• Continuity
Range
• 200 to 500V
• 200 to 400A
• Below 600 Ohms
Accuracy
• (±1.2% rdg + 5dgts) 40Hz to 500 Hz
• (±1.5% rdg + 5dgts) 50Hz to 600 Hz
Analogue Clamp-On Amp-seeker®
Rugged analog display clamp-on meter measuring AC current, AC voltage,
Ohms, continuity and temperature (with optional probe). Unit includes high
quality probe set, spare fuse (0.5A / 250V), carrying case, "AA" battery and
wrist strap.
Analogue Clamp-On Amp-seeker®
Part #
Features
Specifications
46-AC600
Function
• VAC
• ACA
• Temperature
• Continuity
Range
• 0 to 600V
• 0 to 600A
• -50°C to 200°C (-26°F to 392°F)
• 0-2K Ohm/ 0-200K Ohm
Accuracy
• ±3% of full scale
• ±3% of full scale
• ±3% of full scale
• ±3% of full scale
Digital Clamp-On Amp-seeker®
Professional auto-ranging clamp-on volt, ohm amp meter is a multi-functional
electrical testing workhorse, capable of performing all of your maintenance
and inspection needs. Large 1⁄2" × 31⁄2" digit (1999 count) LCD display with
low battery and data/ peak hold indicators, fully circuit protected to 1100DCV/
800AC/ 1000A. Unit includes high quality probe set, carrying case and battery.
Digital Clamp-On Amp-seeker®
Part #
Features
Specifications
46-AC610
Function
• VAC
• VDA
• ACA
• Resistance
• Frequency Count
• Continuity Check
Range
• 200mV to 750V
• 1V to 1,000V
• 20mA to 600A
• 200m Ohm -20K Ohm
• 10Hz to 2 KHz
• Forward or reverse
Accuracy
• ±3% of full scale
• ±3% of full scale
• ±3% of full scale
Peak Hold Measurements
Overload Protection
• 1000A
• DC1100V / AC800V
Range
• 20 to 600A
• 200 to 750V
Accuracy
• (±1.2% rdg + 3dgts)
• (±0.8% rdg + 2dgts)
46-AC400
Illustrated
46-AC600
Illustrated
46-AC610
Illustrated
Replacement Parts - Electrical Test Instruments
Electrical Testers
