6
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Part #
HP Volts Amps RPM Rot.
Type Body
Shaft
Features
Cross
Reference
O6-R499
1/15
115 1.0 1/1625 CCW PSC/ Open 4.55"
5/16"×2.3"
4 Studs Front
4/370 Cap.
Grainger 3M499B
R3-R348
1/15
115 1.12 2/1550 CCW PSC/ TE 4.1"
3/8"×3.35"
3 Ears/ Cap Inc.
Pin & Ins. Spade
Terms.
Ring Term. Grnd.
Vanee HRV M1703
O1-R465
1/15
115 2.25 3/1550 CCW SP/ Open 4.0" 2.3"×5/16"×2.3"
Internal Fan
Pin Terms.
Ring term. Grnd.
Nutech-Lifebreath 23202,
Elmira stoves,
2868-513-133,152
R3-R334
1/15
115 2.30 1/3000 CCW SP/ Open 4.25"
1/4"×1.50"
Ball Bearing
Internal Fan
Bare Wire Leads
Torrin 7627181, 7627221,
7627271, 7627291, Clare
US-R90671
1/15
115
208
230
2.10 1/1550 CW SP 5.00"
2.24"×5/16"
Mechanical Duty
Removable Studs
Resilient Rings
671, 81671
US-R90672
1/15
115
208
230
2.10 1/1550 CCW SP 5.00"
2.24"×5/16"
Mechanical Duty
Removable Studs
Resilient Rings
672, 81672
R2-R438
1/14
115 1.05 2/1600 CW PSC/ Open 4.25"
5/16"×1.50"
3 Ears Mnt.
Venmar HRV 01038
R3-R366
1/7
115 1.7 3/1630 CW PSC/ Open 4.75" 3.0"×3/8"×3.0"
2 Side Studs
Venmar HRV 02100
R2-R422
1/6
115 2.9 3/1690 CW PSC/ Open 4.90"
3/8"×2.0"
3 Ears
Venmar HRV 02209
3.3" Motors Continued From Previous
3.3" Motors
• Sleeve bearing unless indicated otherwise
