10
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Features
• 48Y Frame
• 5.5" Diameter
• Open Enclosure
• Mounting: Stud, Strap & Base
(Resilient Rings)
• 60 Hz
• Sleeve Bearing
• Shaft: 4.0" × 1/2"
• Reversible
• Permanent Split Capacitor (P.S.C.)
• 40°C Ambient
• Insulation Class B
• Thermally Protected
45°C Ambient
Cross Reference
Rotom HP Voltage AO Smith Diversitech Emerson Fasco Embraco GE Marathon UE Rotom
DD-3583
1/4
115
DL1026
WG840583
1863
D721
E201 3583 X000
533 R43583
DD-3584
1/4 208/230
D1026
WG840584
1971
D725
E202 3584 X001
530 R43584
DD-3585
1/3
115
DL1036
WG840585
1864
D727
E203 3585 X002
532 R43585
DD-3586
1/3 208/230
D1036
WG840586
1972
D923
E204 3586 X003
529 R43586
DD-3587
1/2
115
DL1056
WG840587
1865
D701
E205 3587 X004
531 R43587
DD-3588
1/2 208/230
D1056
WG840588
1973
D703
E206 3588 X005
528 R43588
DD-3589
3/4
115
DL1076
WG840589
8904
D728
E207 3589 X009
678 R43589
DD-3590
3/4 208/230
D1076
WG840590
8905
D729
E208 3590 X010
679 R43590
24 Month
Warranty
+
Direct Drive Motors
Direct Drive Motors
92-A8617
Torsion Flex Bracket
5.0" & 5.5" Dia.
9" & 10" Bolt Circles
92-A8550 -
5" Diameter
92-A8555 -
5.5" Diameter
9" & 10" Bolt Circles
5.5" Diameter for
1/2 HP and above
92-A8556 -
9" Bolt Circle
92-A8557
-
10" Bolt Circle
HEAVY DUTY
115 & 208/230 Volt, 3 Speed, 1075 RPM, Reversible Rotation
Part #
HP Volts Amps Cap.
SPD/RPM Rotation Body Bearing Shaft
DD-3583
1/4
115
4.8 5/370 3/1075 Revers. 4.22" Sleeve 1/2"×4.0"
DD-3584
1/4
208/230 2.0 5/370 3/1075 Revers. 4.22" Sleeve 1/2"×4.0"
DD-3585
1/3
115
5.5 7.5/370 3/1075 Revers. 4.37" Sleeve 1/2"×4.0"
DD-3586
1/3
208/230 2.8 5/370 3/1075 Revers. 4.48" Sleeve 1/2"×4.0"
DD-3587
1/2
115
7.5 10/370 3/1075 Revers. 5.25" Sleeve 1/2"×4.0"
DD-3588
1/2
208/230 3.8 10/370 3/1075 Revers. 5.23" Sleeve 1/2"×4.0"
DD-3589
3/4
115 10.2 15/370 3/1075 Revers. 5.48" Sleeve 1/2"×4.0"
DD-3590
3/4
208/230 5.5 10/370 3/1075 Revers. 5.37" Sleeve 1/2"×4.0"
Capacitor Not Included
