12
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
"A"
Part #
CFM "A" Dim.
66-RFC300
300
6.75"
66-RFC400
400
8.25"
66-RFC600
600
9.00"
Fan Coil Blowers
Heating & Air Conditioning • High Rise Apartment • Condominium • Hotel
Fan Coil Motors
Heating & Air Conditioning • High Rise Apartment • Condominium • Hotel
ONE MOTOR DOES ALL THREE! Bedroom, Living Room, Common Area.
Motors Sold Separately
Applications
• Heating & Air Conditioning
• High Rise Apartment
• Condominium
• Hotel
Wiring Diagram
- 1/8 HP
- 1/10 HP
- 1/12 HP
Direct Replacement For:
• Climetec
• Snyder-General
• Temspec
• Unilux
DD-030 Replaces :
5KCP39DGV279S
M4-R2197
With 92-A8551
8.37" bracket
M4-R2195
Illustrated
M4-R2198
Motor Only
9" or 10" Bolt Circle
Replaces:
UE & Temspec DE3E142N
Part #
HP Volts Amps Type
Cap.
RPM Rot. Body Frame Bearing Shaft
M4-R2197
1/14
115 1.25 PSC 7.5/370 3/820 CCW 3.8"
5.0"
Sleeve 3.4"×1/2"
M4-R2198
1/14
115 1.25 PSC 7.5/370 3/820 CCW 3.8"
5.0"
Sleeve 3.4"×1/2"
Part # HP Amps Cap.
RPM Body Frame
Shaft
DD-030
1/6
2.6
Inc.
5/950 3.57"
48 1/2"×4.5"
Fan Coil Motors
Temspec Replacement Fan Coil Motors
PSC Fan Coil Motors
ECM Fan Coil Motors
Part # HP Volts Amps Type Cap.
RPM Rot. Body Frame Bearing Shaft
Cross
M4-R2194
1/14
115 1.25 PSC 7.5/370 3/820 CCW 4.0"
5.0"
Sleeve 3.4"×1/2"
DE3E141N
M4-R2195
1/12
115 2.10 PSC 7.5/370 3/740 CCW 4.6"
5.0"
Sleeve 3.4"×1/2"
DE3F056N
M4-R2196
1/8
115 2.50 PSC 7.5/370 3/850 CCW 4.5"
5.0"
Sleeve 3.9"×1/2"
DE3G110N
UE-799
1/8
115 2.60 PSC 5/370 5/1075 CCW 3.75" 5.0"
Sleeve 5.0"×1/2"
L350,L450,L600,
UE DA3E200,
DA3F100, DA3G142
Part #
HP
Volts Amps Spd/RPM Dia Rot
Type Cap
Shaft
EC-FC-1893
1/15
115 0.96 6/1550 4.0" CCW PSC 6.3/450 1/2" × 7.26"
EC-FC-1895
1/4
115 3.80 6/1550 4.8" CCW PSC 18/450 1/2" × 7.26"
Features
•Type: PSC • Double Shaft • Volts: 115/60 Hz • Enclosure: Open end-bells • Thermally Protected
• Capacitor Included • Ball Bearing • Insulation Class B • Protection Class IP20 • Base Mount Included
Features
• Drop-in replacement • Brushless DC • 3 Speeds • 5 1/8" Diameter • 54" lead length
• ECM with internal control • Long life ball bearings • Rotors are isolated from shaft to
reduce motor vibration • Saves an average of 69% on energy usage • Runs cooler
Part # HP Volts Rot
Amps RPM Range
Shaft
Frame
M4-R2189
1/10
120 CWLE 1.56 3/1100,900,700 9.3" × 1/2" x 9.3"
5.0"
