8
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
48 Frame - 4 Speed - Multi-HP - Direct Drive
Part #
HP Volts Amps Cap.
SPD/RPM Rotation A Dim. Bearing Shaft
DD-1314
1/3
115 6.0 7.5/370 4/1075 Revers.
4.40"
Sleeve 1/2"×6"
Cross Reference
Rotom HP Voltage AO Smith Carrier
Coleman Emerson Lennox ICP GE Marathon Rotom
DD-1314
1/3
1/4
1/6
1/7
115
DL1026
DL1036
HC41SE117
HC41SE121
P257 8583
P257 8585
1486-236P
11864
1863
1864
P-8-7505
32663
LFM13
1009045
1008415
3583
3585
X003
R43583
R43585
24 Month
Warranty
Features
• 48 Frame
• 5.5" Diameter
• Open Enclosure
• Mounting: Stud, Strap & Base (Resilient Rings)
• 60 Hz
• Sleeve Bearing
• Shaft: 1/2" × 6.0"
• Reversible
• Permanent Split Capacitor (P.S.C.)
• 60" Coloured Electrical Leads
• Insulation Class B
• Thermally Protected
+
Direct Drive Motors
5.5" Direct Drive Motor
5.0" Direct Drive Motors
Direct Replacement For:
• Coleman • Carrier
• Lennox • York
Part # HP Volts Amps Cap.
SPD/RPM Rotation Body Bearing Shaft
Cross
UE-98
1/8
115
5.2
-
3/1050
CCW 3.8" Sleeve 3.8" × 1/2"
Fasco D178, D356, UE98
M4-R2385
1/5
115
6.5
-
3/1050
CCW 3.9" Sleeve 5.5" × 1/2"
Fasco D158, UE385, 90
M4-R2429
1/5
208/230 3.2
-
3/1050
CCW 3.9" Sleeve 5.5" × 1/2"
Fasco D318, UE429
M4-R2679
1/4
115
10.0
-
3/1050
Rev.
4.7" Sleeve 2.2" × 1/2"
Lennox,York, Carrier
M4-R2368
1/5
115
3.5
4/370 4/1030
CCW 4.5" Sleeve 3.5" × 1/2"
1268, 024-17903-703, HC37MA135,
P8-3789,90,3527,29,4662,9662
M4-R2390
1/5
115
3.2 7.5/370 3/1075
Rev.
3.9" Sleeve 5.5" × 1/2"
UE390,York 24-22489-000, Bohn 5002L,
5003F
M4-R2391
1/5
208/230 1.3 7.5/370 3/1075
Rev.
3.9" Sleeve 5.5" × 1/2"
Fasco D262, D1016, UE391, 515
M4-R2395
1/4
115
4.9
5/370 3/1075
Rev.
4.1" Sleeve 4.5" × 1/2"
Fasco D150
M4-R2628
1/4
208/230 1.8
5/370 5/1075
Rev.
4.1" Sleeve 2.5" × 1/2"
Fasco D151
