SECTION
PAGE
DATE
Sump Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
16
A
Professional Plumbing
Series BUS
Battery Backup
Submersible
1/13
MODEL NUMBER
BUS
PART NUMBER
100940
PUMPING CAPACITY
1000 GPH @ 10 feet
POWER DRAW:
NOTE: The lower the AMP draw, the longer the pump will run on the battery.
6 Amps @ 12 Volts
CHARGER STRENGTH:
NOTE: The higher the AMPS, the faster the charger will recharge the battery.
0.4 Amps
Approx. time to recharge a fully discharged battery.
48 Hours
Approx. continuous pumping with recommended battery
6 - 12 Hours
A 12 Volt Deep Cycle Marine Battery is recommended (Not Supplied)
IMPORTANT !
1.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
2.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
