Sump Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
12
A
Professional Plumbing
Series SP33HT
High Temperature - 1/2" Spherical Solids Handling
Manual & Automatic, Submersible Sump /Effluent
MODEL NO PART NO HP VOLT/PH Hz
RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
CORD
LENGTH
CORD
SIZE
CORD
TYPE
SP33HTX
113667 1/3
120/1
60
3450
B
4.1
20 ft. (6m)
18/3
SJTOW
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
3.) MUST USE A
HIGH TEMPERATURE
WIDE ANGLE LEVEL CONTROL IN HIGH TEMPERATURE APPLICATIONS.
inches
(mm)
1/13
