Sump Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
22
A
www.cranepumps.com
Professional Plumbing
1/13
Series BP
3/4" Spherical Solids Handling
Manual & Automatic - Submersible
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
3.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
BP314 096727 1/3 115/1 60 1750 A 8.0 19.0 14/3 SJTOW 0.375 (9.5)
BP314A 096728 1/3 115/1 60 1750 A 8.0 19.0 14/3 SJTOW 0.375 (9.5)
BP314AU 096729 1/3 115/1 60 1750 A 8.0 19.0 14/3 SJTOW 0.375 (9.5)
BP314VF 100834 1/3 115/1 60 1750 A 8.0 19.0 14/3 SJTOW 0.375 (9.5)
BP314BR 096732 1/3 115/1 60 1750 A 8.0 19.0 14/3 SJTOW 0.375 (9.5)
BP314ABR 096733 1/3 115/1 60 1750 A 8.0 19.0 14/3 SJTOW 0.375 (9.5)
BP314AUBR 096734 1/3 115/1 60 1750 A 8.0 19.0 14/3 SJTOW 0.375 (9.5)
BP314VFBR 100835 1/3 115/1 60 1750 A 8.0 19.0 14/3 SJTOW 0.375 (9.5)
BP324 096730 1/3 230/1 60 1750 A 4.0 13.0 14/3 SJTOW 0.375 (9.5)
BP324AU 096731 1/3 230/1 60 1750 A 4.0 13.0 14/3 SJTOW 0.375 (9.5)
BP324BR 096735 1/3 230/1 60 1750 A 4.0 13.0 14/3 SJTOW 0.375 (9.5)
BP324AUBR 096736 1/3 230/1 60 1750 A 4.0 13.0 14/3 SJTOW 0.375 (9.5)
Mechanical Switch on BP-A, cord 16/2, SJOW, Piggy-Back Plug.
Mechanical Switch on BP-AU, cord 14/2, SJOW
Vertical Switch on BP-VF, cord 16/2, SJOW, Piggy-Back Plug
BP314VF, BP314VFBR BP314A, BP314ABR,
BP314. BP314BR, BP324, BP324BR (Less Float)
BP314AU, BP314AUBR
BP324AU, BP324AUBR
