Submersible Non-Clog Pumps
5
C
Professional Plumbing
10/05
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
Series SE-HT
2" Spherical Solids Handling
High Temperature - Manual & Automatic
DISCHARGE .............................
2” NPT, Female, Vertical
LIQUID TEMPERATURE ..........
200°F (93°C) Continuous
VOLUTE.....................................
Cast Iron ASTM A-48, Class 30
MOTOR HOUSING ....................
Cast Iron ASTM A-48, Class 30
SEAL PLATE ............................
Cast Iron ASTM A-48, Class 30
IMPELLER:
Design
................
2 Vane, Open with pump out vanes on back side
Dynamically Balanced, ISO G6.3
Material
.............
Cast Iron ASTM A-48, Class 30
SHAFT
......................................
416 Stainless Steel
SQUARE RINGS .......................
Buna-N
HARDWARE ..............................
300 Series Stainless Steel
PAINT .........................................
Air Dry Enamel
SEAL:
Design
..............
Single Mechanical, Oil Filled Reservoir,
Secondary Exclusion Seal
Material
..............
Carbon/Ceramic/Buna-N
Hardware -300 Series Stainless
CORD ENTRY ...........................
15 ft. (5m) Cord with plug On 115 volt, Pressure
Gromment for sealing and strain relief
UPPER BEARING......................
Single Row, Ball, Oil Lubricated
LOWER BEARING.....................
Single Row, Ball, Oil Lubricated
MOTOR:
Design
...............
NEMA L Torque Curve, Oil Filled, Squirrel Cage
Induction
Insulation
..........
Class B
SINGLE PHASE.........................
Permanent Split Capacitor (PSC)
Includes Overload Protection in Motor
LEVEL CONTROL ....................."A" -
Wide Angle, PVC, Mechanical, 15 ft (5m) cord
with Piggy-Back Plug, N/O
"AU"-
Wide Angle, Polypropylene, Mechanical, N/O
Integral to pump. ON and OFF Points are adjustable
OPTIONAL EQUIPMENT ...........
Seal Material, Additional Cord, Strainer
Series: SE-HT
(SE411HT & SE421HT)
.4HP, 1750RPM, 60Hz
DESCRIPTION:
SUBMERSIBLE NON-CLOG SEWAGE PUMP DESIGNED
FOR
HIGH TEMPERATURE
RAW SEWAGE
APPLICATIONS
