Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
6
C
Professional Plumbing
4/04
inches
(mm)
SE411HT, SE421HT
SE411HTA
SE411HTAU, SE421HTAU
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
SE411HT
096764 0.4
115/1
60 1750
A
10.0
26.0
14/3 SOOW 0.560 (14.2)
SE411HTA
096765 0.4
115/1
60 1750
A
10.0
26.0
14/3 SOOW 0.560 (14.2)
SE411HTAU
096766 0.4
115/1
60 1750
A
10.0
26.0
14/3 SOOW 0.560 (14.2)
SE421HT
096767 0.4
230/1
60 1750
A
4.0
13.0
14/3 SOOW 0.560 (14.2)
SE421HTAU
096768 0.4
230/1
60 1750
A
4.0
13.0
14/3 SOOW 0.560 (14.2)
Mechanical Switch on SE-HTA, cord 14/2, SJOW, 0.370 (9.4mm) O.D. Piggy-Back Plug
Mechanical Switch on SE-HTAU, cord 14/2, SJOW, 0.370 (9.4mm) O.D.
Series SE-HT
2" Spherical Solids Handling
Manual & Automatic - High Temperature
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
3.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
4.) MUST USE A
HIGH TEMPERATURE
WIDE ANGLE LEVEL CONTROL IN HIGH TEMPERATURE APPLICATIONS.
