Submersible Non-Clog Pumps
1
C
Professional Plumbing
3/13
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
DESCRIPTION:
SUBMERSIBLE NON-CLOG SEWAGE PUMP DESIGNED
FOR TYPICAL RAW SEWAGE APPLICATIONS
Series SEV412
2" Spherical Solids Handling
Manual & Automatic
DISCHARGE ...............................
2” NPT, Female, Vertical
LIQUID TEMPERATURE .............
77°F (25°C) Continuous
MOTOR HOUSING ......................
Cast Iron
PUMP BODY ...............................
Cast Iron
IMPELLER:
Design
....................
Multi-Vane, Vortex
Material
..................
Cast Iron
SHAFT
........................................
416 Stainless Steel
O-RINGS ......................................
Buna-N
HARDWARE ................................
300 Series Stainless Steel
PAINT ...........................................
Air Dry Enamel
CORD ENTRY..............................
20 ft. (6m) Quick Disconnect Cord with
plug on 115 Volt, Pressure Gromment for
sealing and strain relief
SEAL:
Design
....................
Single Mechanical, Oil Filled Reservoir
Material
...................
Carbon/Ceramic/Buna-N
Hardware - 300 Series Stainless
UPPER BEARING........................
Single Row, Ball, Oil Lubricated
LOWER BEARING.......................
Single Row, Ball, Oil Lubricated
MOTOR:
Design
....................
Oil Filled
Insulation
...............
Class B
SINGLE PHASE...........................
Permanent Split Capacitor (PSC)
Includes Overload Protection in Motor
LEVEL CONTROL:
SEV412...................None
SEV412A.................Wide Angle, Mechanical, 20 ft (6m) cord
Pipe Mounted
SEV412VF ..............Vertical Float, PVC, Snap Action
SEV412VFT............Attached Vertical Float, PVC, Snap Action
SEV412AT ..............Wide Angle, Mechanical, 20 ft (6m) cord
Pump Mounted
SEV412DT..............Diaphragm Switch, Press Operated, snap
Action, Normally Open, 20ft. (6m) Cord
Series: SEV
0.5 HP, 3450RPM, 60Hz
CSA 108 - File No. LR16567
UL 778
NRTL\C
