Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
8
C
www.cranepumps.com
Professional Plumbing
Series SE/SEV-511/521
2" Spherical Solids Handling
Manual & Automatic
3/13
inches
(mm)
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
SE511 096752 0.5 115/1 60 1750 A 12.0 26.0 14/3 SJTOW 0.375 (9.5)
SE511A 096753 0.5 115/1 60 1750 A 12.0 26.0 14/3 SJTOW 0.375 (9.5)
SE511AU 096754 0.5 115/1 60 1750 A 12.0 26.0 14/3 SJTOW 0.375 (9.5)
SE511VF 100837 0.5 115/1 60 1750 A 12.0 26.0 14/3 SJTOW 0.375 (9.5)
SE521 096755 0.5 230/1 60 1750 A 6.2 13.0 14/3 SJTOW 0.375 (9.5)
SE521AU 096756 0.5 230/1 60 1750 A 6.2 13.0 14/3 SJTOW 0.375 (9.5)
SEV511 096757 0.5 115/1 60 1750 A 12.0 26.0 14/3 SJTOW 0.375 (9.5)
SEV511A 096758 0.5 115/1 60 1750 A 12.0 26.0 14/3 SJTOW 0.375 (9.5)
SEV511AU 096759 0.5 115/1 60 1750 A 12.0 26.0 14/3 SJTOW 0.375 (9.5)
SEV511VF 100838 0.5 115/1 60 1750 A 12.0 26.0 14/3 SJTOW 0.375 (9.5)
SEV521 096760 0.5 230/1 60 1750 A 6.2 13.0 14/3 SJTOW 0.375 (9.5)
SEV521AU 096761 0.5 230/1 60 1750 A 6.2 13.0 14/3 SJTOW 0.375 (9.5)
Mechanical Switch on SE-A, cord 16/2, SJOW, Piggy-Back Plug
Mechanical Switch on SE-AU, cord 14/2, SJOW, 0.370 (9.4mm) O.D.
Vertical Switch on SE-VF, cord 16/2, SJOW, 0.320 (8.1mm) O.D. Piggy-Back Plug
SE511VF
SEV511VF
SE511, SE521, SEV511, SEV521 (Less Float)
SE511A, SEV511A
SE511AU, SE521AU,
SEV511AU, SEV521AU
