Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
2
C
www.cranepumps.com
Professional Plumbing
Series SEV412
2" Spherical Solids Handling
Manual & Automatic
inches
(mm)
3/13
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
LENGTH
CORD
SIZE
CORD
TYPE
SEV412 101292 0.5 115/1 60 3450 H 10.50 18.6 20 ft. (6m) 14/3 SJTOW
SEV412A 101293 0.5 115/1 60 3450 H 10.50 18.6 20 ft. (6m) 14/3 SJTOW
SEV412VF 101294 0.5 115/1 60 3450 H 10.50 18.6 20 ft. (6m) 14/3 SJTOW
SEV412AT 103544 0.5 115/1 60 3450 H 10.50 18.6 20 ft. (6m) 14/3 SJTOW
SEV412VFT 110404 0.5 115/1 60 3450 H 10.50 18.6 20 ft. (6m) 14/3 SJTOW
SEV412DT 119614 0.5 115/1 60 3450 H 10.50 18.6 20 ft. (6m) 14/3 SJTOW
SEV412VF
SEV412A
SEV412 (Less Float)
SEV412AT (Attached to Motor Housing)
SEV412VFT
SEV412DT
