125
Specifications are subject to change without notice
Accessories
NEMA D FLANGE KIT WATTSAVER
®
MOTORS
Special conversion kit for use exclusively on WATTSAVERe
®
cast iron
frame motors.
Frame
Catalogue Number
App. Wt. (lbs.)
182T-184T
164077
10
213T-215T
175050
12
254T-256T
175051
18
284T-286T
175052
20
324T-326T
175053
29
364T-365T
175054
39
404T-405T
174055
49
444T-445
174076
65
447T-449T
175891
85
D Flange Kit
App. Wgt.
Frame
Enclosure
Catalogue Number
(lbs.)
143T-145T
Enclosed
163115
6
182T-184T
Enclosed
175658
Ø
12
Open
175101
12
ODP/TEFC
175694
H
12
213T-215T
Open
175114
14
Enclosed
175115
14
254T-256T
Open
163027
25
Enclosed
163032
25
284T-286T
Open
163028
42
Enclosed
163024
42
324T-326T
Open
163029
57
Enclosed
163025
57
364T-365T
Open
163044
72
364T-365T
Enclosed
163034
72
404T-405T
Open
163041
80
404T-405T
Enclosed
163045
80
444T-445T
Open
163077
100
444T-445T
Enclosed
163102*
100
444TS-445TS Enclosed
163125
±
100
447T-449T
Enclosed
163104
140
447TS-449TS Enclosed
163126
±
140
H
For use with rolled steel motor
DRIP COVER KITS
",Ê , **,"" Ê "/",-ÊUÊ
CAST IRON
Catalogue
App. Wgt.
Frame
Number
(lbs.)
180
180Dripcover
3
210
210Dripcover
4
250
250Dripcover
7
Catalogue
App. Wgt.
Frame
Number
(lbs.)
48-S56
175003
2
48-S56
175298
U
2
56
175004
2
143T-145T
175004
2
182T-184T
175030
3
213T-215T
175846
3
MOTOR ACCESSORIES
FIELD INSTALLED
NEMA D FLANGE KITS
STEEL AND CAST IRON
FRAME MOTORS
Includes parts to convert a rigid base mounted motor to NEMA
D face with base.
Shaded frame indicates cast iron motor kits for 150 and 170
series motors.
NOTE: The D Flange Kits can
only
be used on rigid base
motors. They will not fit NEMA C face motors.
CHEMICAL SERVICE/
SEVERE DUTY CONVERSION KITS
Cast iron fan covers for 150 Series and 170 Series
cast iron motors. Designed to easily convert TEFC
motors to all cast iron construction. All these motors
have inert, corrosion resistant fiber filled thermoplastic
fan as standard. Kit includes one cast iron fan cover.
DRIP-COVER KITS
FOR DRIP-PROOF MOTORS
Each kit includes one drip-cover. Designed to
protect drip-proof motors from rain, snow and
ice when mounted outdoors in a vertical position.
Catalogue
App. Wgt.
Frame
Number
(lbs.)
213T-215T
175849
12
DRIP-COVER KIT
FOR TEFC MOTORS
For use with 1750 RPM steel frame motors only.
U
For use with motors having “P” suffix on date code.
D Flange Kit
App. Wgt.
Frame
Enclosure
Catalog Number
(lbs.)
182T-184T
Enclosed
175843*
¨
14
182T-184T
Enclosed
175807
¡
14
213T-215T
Enclosed
175115
14
324T-326T
Open
175455
57
364T-365T
Open
175602
Æ
72
Enclosed
175604
Æ
72
*Locked bearing
RODENT SCREEN KITS
Catalog
App. Wgt.
Frame
Enclosure
Number
(lbs.)
182T-184T*
Open
175872
1
213T-215T*
Open
175871
1
254T-256T
Open
175873
2
284T-286T
Open
175874
3
324T
Open
175894
5
326T
Open
175875
4
*Rolled steel frame only.
?
Use this kit for 182-4T and S213T motors with catalog numbers 131454 and higher, or with a G prefix.
Both open and enclosed motors in this series use the same kits as ventilation is in the frame of the motor.
H
For use with 213T-215T 3450 RPM motors only in rolled steel.
u
For use with motors having “P” suffix on date code.
t
For use with motors having catalog numbers 15XXXX, G15XXXX, or 17XXXX.
_
Not for use with WATTSAVERe
®
motors.
¨
For use with motors having date codes earlier than May 2003.
¡
For use with motors having date codes May 2003 and later.
P
For use with 1140 and 1750 RPM motors only.
Æ
WATTSAVERe
®
II design, having oversized frame body.
Ø
For 3450 RPM motors use WATTSAVER
®
kit 175807
±
For 3450 RPM motors
