WET ENDS
SKU Number List Price Code Description
EXECUTIVE SIDE DISCHARGE PUMP PARTS
Part Number Description List Price Code
1 715-1201 ................ Drain Plug ...................................................................$ 2.94 A
2 805-0111................. Drain Plug O-Ring.......................................................$ 0.84 A
3 311-1220 ................ 2” Face Plate...............................................................$ 54.50 A
3 311-1210 ................ 2½” Face Plate............................................................$ 54.50 A
4 805-0261 ................ Volute O-Ring..............................................................$ 6.86 A
5 319-1380 ................ Impeller Sleeve 1-3 HP ...............................................$ 7.70 A
5 319-1370 ................ Impeller Sleeve 4-5 HP ...............................................$ 7.70 A
6 310-4220 ................ 1 HP Impeller ..............................................................$ 33.20 A
6 310-4210 ................ 2 HP Impeller ..............................................................$ 33.20 A
6 310-4200 ................ 3 HP Impeller ..............................................................$ 33.20 A
6 310-4190 ................ 4 HP Impeller ..............................................................$ 33.20 A
6 310-4180 ................ 5 HP Impeller ..............................................................$ 33.20 A
7&8 SEAL-03................. Seal, 5/8 Reverse Style ..............................................$ 9.26 A12-10
9 315-1220 ................ 56 Frame Volute Back.................................................$ 42.90 A
9 315-1240 ................ 48 Frame Volute Back.................................................$ 42.90 A
10 313-1400 ................ Slinger.........................................................................$ 1.42 A
672-4350 barbed adapter will thread where the plugs are on these Wet Ends.
To get union size measure outside diameter of threads and subtract 1”
Eg. If measures 3” use 2” union
9 10
8
7 6
5 4
3
1 2
NOTE
Older parts not interchangeable with new parts
EXECUTIVE WET END 2” Centre Suction, 2” Side Discharge
NOTE: 48 Frame is max rated. Call for appropriate impeller for all models.
310-1870 $ 121.84 A8-5 1 HP 48 Frame
310-1880 $ 121.84 A8-5 1.5 HP 48 Frame
310-1890 $ 121.84 A8-5 2 HP 48 Frame
310-1900 $ 121.84 A8-5 3 HP 48 Frame
310-1910 $ 121.84 A8-5 4 HP 48 Frame
310-1920 $ 121.84 A8-5 4.5 HP 48 Frame
310-1720 $ 121.84 A8-5 2 HP 56 Frame
310-1730 $ 121.84 A8-5 3 HP 56 Frame
310-1740 $ 121.84 A8-5 4 HP 56 Frame
310-1750 $ 121.84 A8-5 5 HP 56 Frame
EXECUTIVE WET END 2½” Centre Suction, 2” Side Discharge
NOTE: 48 Frame is max rated. Call for appropriate impeller for all models.
310-1820 $ 121.84 A8-5 2 HP 48 Frame
310-1860 $ 121.84 A8-5 4 HP 48 Frame
310-1850 $ 121.84 A8-5 4.5 HP 48 Frame
310-1830 $ 121.84 A8-5 5 HP 48 Frame
310-1460 $ 121.84 A8-5 1 HP 56 Frame
310-1480 $ 121.84 A8-5 2 HP 56 Frame
310-1500 $ 121.84 A8-5 3 HP 56 Frame
310-1440 $ 121.84 A8-5 4 HP 56 Frame
310-1510 $ 121.84 A8-5 5 HP 56 Frame
