“S” FRONT
NOTE
The “S” front has 3 “steps” inside the intake.
The “SW” front has 2 “steps” inside the intake.
“SW” FRONT (4HP) -
ULTIMA PLUS WIDE
PLUMBING FRONT CONFIGURATIONS
10
11
8
7
5
9
2
3
4
6
ULTIMA SPAS
2
PPSFVBOLT
.......... Volute Bolt, Short ........................................................$
3.16
A
3
PPULPLUG
............ Drain Plug ...................................................................$
2.32
A
4
PPULPLUGO/R
..... Drain Plug O-Ring.......................................................$
4.74
A
5
PPULAVF
............... Volute Front 1½” bottom intake/1½” top discharge .....$ 104.48
A
5
PPULSQF
.............. Volute Front 2” centre intake/1½” top discharge .........$ 107.06
A
5
PPULSVF
............... Volute Front 2” centre intake/2” side discharge ..........$ 107.06
A
5
PPULTVF
............... Volute Front 2” centre intake/1½” side discharge ....... P.O.R.*
A
5
PPULXVF
............... Volute Front 1½” centre intake/1½” top discharge ......$ 99.94
A
5
PPULYVF
............... Volute Front 1½” centre intake/1½” side discharge ....$ 107.06
A
6
PPSFVNUT
............ Volute Nut ................................................................... P.O.R.*
A
7
PPUF10IMP
........... UF Impeller, 1 HP (Black)............................................$ 37.74
A
7
PPUF15IMP
........... UF Impeller, 1.5 HP (Red/Green)................................$ 36.14
A
7
PPUF20IMP
........... UF Impeller, 2 HP (Red)..............................................$ 38.50
A
7
PPUF7IMP
............. UF Impeller, 3/4 HP (Grey)..........................................$ 28.18
A
8
PPUFVO/R
............. UF Pump Volute O-Ring .............................................$
8.72
A
9
SEAL-UJ2
.............. Pump Seal (includes Heat Sink & Boot) .....................$ 26.66
A
10
PPULVB
................. Volute Back .................................................................$ 83.54
A
11
PPSFSLING
........... UF/SF Slinger .............................................................$
5.92
A
ULTIMA PLUS WIDE
1
PPULBOLT-P
......... Volute Bolt - 1½” .........................................................$
3.04
A
5**
PPULSWVF
...........Wide Volute Front (Green/Orange/Red/Black)............$ 107.06
A
7
PPUF5IMP
............. UF Impeller 5 HP.........................................................$ 39.24
A
7**
PPUF400IMP
......... 10.5 amp Impeller (Red/Black) ...................................$ 36.14
A
7**
PPUF418IMP
......... 12 amp Impeller (Black/Green/Red) ...........................$ 36.14
A
10**
PPULVBW
..............Wide Volute Back........................................................$ 83.14
A
DUALLY
7
PPUFDUAL15
........ Impeller, 1.5 HP (Red/Green/Black)............................$ 36.14
B
7
PPUFDUALIMP
..... Impeller (Red/Green/Orange/Red)..............................$ 39.64
B
BIG FOOT
PPBF20IMP
........... Impeller, 2 HP (Red/Black/Red) .................................. P.O.R.*
A
PPBF40IMPPGP
.... Impeller, 4 HP (Purple/Grey/Purple)............................ P.O.R.*
A
ULTIMAX
PPUMVB
................ Volute Back, Ultimax ................................................... P.O.R.*
A
PPUMVF
................ Volute Front, Ultimax...................................................$ 100.38
A
PPUM3IMP
............. Impeller, 3 HP (Green/Black/Red)...............................$ 35.42
A
PPUM2IMP
............. Impeller, 2 HP (Green/Brown/Red) .............................$ 38.92
A
PPUM15IMP
........... Impeller, 1.5 HP, Uprated to 3 HP ...............................$ 38.92
A
(Green/Blue/Red/Blue)
** Items for high amp / high HP only. Call for details.
