FILTERS & P ARTS RAINBOW
RAINBOW RTL / RCF TOP LOAD FILTER
7” Mount Hole
Part Number ........... Description ..................................................................List Price Code
17-2504 .................. RTL 50’ Complete Filter 2” Slip ...................................$ 231.84 A
17-2524 .................. RCF 50’ Filter & Dispenser 2” Slip ..............................$ 276.30 A
17-2503 .................. RTL 75’ Complete Filter 2” Slip ...................................$ 274.58 A
1 17-2214 .................. Lid Lock Ring ..............................................................$ 20.88 A
2 172224X ................. Drain Vent, Black ........................................................$ 7.02 A
3 17-2221 .................. O-Ring.........................................................................$ 1.34 A
4 17-2222 .................. Cartridge Gasket.........................................................$ 3.38 A
5 17-2385 .................. Lid Assembly, Complete..............................................$ 31.04 A
6 17-2223 .................. Lid O-Ring...................................................................$ 7.08 A
7 C-4950 .................... Cartridge, 50’...............................................................$ 48.78 A16-5
7 C-4975 .................... Cartridge, 75’...............................................................$ 64.60 A4-5
8 17-2375 .................. Lock Spring Screw ......................................................$ 1.88 A
9 17-2374 .................. Lock Spring .................................................................$ 7.02 A
10 17-2682 .................. 2” Bypass Valve ..........................................................$ 11.16 A
11 17-2428 .................. Cartridge Housing 2” Slip ...........................................$ 99.72 A
12 17-2370 .................. Lower Lock Ring .........................................................$ 15.14 A
13 17-2542BLK ........... Niche & Cover, Black ..................................................$ 37.34 A
14 17-2452 .................. RCF-RTL Base............................................................$ 14.60 A
PARTS FOR 17-2540 (found on page 32) CHLORINATOR/BROMINATOR DISPENSER
15 17-2401 .................. RCF Dispenser Check Valve Screen ..........................$ 1.88 A
16 17-2406 .................. RCF Dispenser Check Valve Assembly .....................$ 6.20 A
17 17-2451 .................. RCF Dispenser Bottom O-Ring...................................$ 1.90 A
RAINBOW LILY PAD DFML FILTER
7” Mount Hole
Part Number ........... Description ..................................................................List Price Code
17-2674 .................. DFML 50' Skim Complete Filter ..................................$ 226.42 A
17-2674DG ............. DFML 50' Skim Complete Filter - Dark Grey...............$ 226.42 A
1 17-2660 .................. Lily Skimmer Float Assembly - White..........................$ 15.24 A
1 17-2660-G .............. Lily Skimmer Float Assembly - Grey ...........................$ 15.24 A
1 17-2660BLK ........... Lily Skimmer Float Assembly - Black ..........................$ 15.24 A
2 17-2661 .................. Lily Basket - White ......................................................$ 17.60 A
2 17-2661-BLK .......... Lily Basket - Black.......................................................$ 17.60 A
2 17-2661-G .............. Lily Basket - Grey........................................................$ 17.60 A
3 17-2662 .................. Basket with Dispenser ................................................$ 72.28 A
3 17-2662G ............... Basket with Dispenser - Grey .....................................$ 78.20 A
4 C-4335 .................... Cartridge (DFML 35) ...................................................$ 41.34 A4-5
4 C-4950 .................... Cartridge (DFML 50) ...................................................$ 48.78 A16-5
5 17-2665 .................. DFML Body-25............................................................$ 120.20 A
5 17-2669DG ............. DFML Body-50 - Dark Grey ........................................$ 128.92 A
6 17-2226 .................. Bypass Assembly........................................................$ 5.12 A
7 17-2682 .................. 2” Bypass Valve ..........................................................$ 11.16 A
8 17-2370 .................. Lower Lock Ring .........................................................$ 15.14 A
9 17-2691 .................. Safety Flange .............................................................$ 23.02 A
11
4
9
12
16
15
17
10
3
1
7
2
2
4
6
5
PARTS FOR 17-2540
CHLORINATOR/BROMINATOR
DISPENSER
Complete filter does not include Base (14) part # 17-2452
or Niche & Cover (13) part # 17-2452BLK
13
14
1
2
9
5
3
6
7
8
4
