PUMP PARTS
FLO MASTER FMCP PUMP PARTS
Part Number Description List Price Code
2 92770603 ............... Volute ..........................................................................$ 52.98 A
3 SEAL-01 ................. 5/8” Pump Seal ...........................................................$ 9.26 A25-10
4 91693551 ............... .75 HP Impeller ...........................................................$ 28.16 A
4 91693601 ............... 1 HP Impeller ..............................................................$ 28.16 A
4 91693651 ............... 1.5 HP Impeller ...........................................................$ 29.80 A
4 91693700 ............... 2 HP Impeller ..............................................................$ 29.80 A
5 92200270 ............... O-Ring, Volute.............................................................$ 5.60 A
6 92830062 ...............Wear Ring ...................................................................$ 5.96 A
7 91231402 ............... Cover, Suction.............................................................$ 39.42 A
8 99730050 ............... Screw ..........................................................................$ 3.38 A
9 92200120 ............... O-Ring Pipe Plug ........................................................$ 5.64 A
10 92290010 ............... Pipe Plug ¼” NPT .......................................................$ 5.96 A
FLO MASTER FMHP PUMP PARTS
Part Number Description List Price Code
2 92770501 ............... Volute ..........................................................................$ 47.70 A
3 SEAL-01 ................. 5/8” Pump Seal ...........................................................$ 9.26 A25-10
4 91693551 ............... .75 HP Impeller ...........................................................$ 28.16 A
4 91693601 ............... 1 HP Impeller ..............................................................$ 28.16 A
4 91693651 ............... 1.5 HP Impeller ...........................................................$ 29.80 A
4 91693700 ............... 2 HP Impeller ..............................................................$ 29.80 A
5 92200090 ............... O-Ring, Volute.............................................................$ 5.64 A
6 92830062 ...............Wear Ring ...................................................................$ 5.96 A
7 91231301 ............... Cover, Suction.............................................................$ 35.76 A
8 99730050 ............... Screw ..........................................................................$ 3.38 A
9 92200120 ............... O-Ring Pipe Plug ........................................................$ 5.64 A
10 92290010 ............... Pipe Plug ¼” NPT .......................................................$ 5.96 A
FLO MASTER XP SERIES PUMP PARTS
Part Number Description XP Series List Price Code
2 92770705 ............... Volute - 48 Frame ............................ XP2, XP2e ........$ 47.70 A
2 92770715 ............... Volute - 56 Frame, 6.1” DIA ...................XP2..............$ 83.46 A
2 92770725 ............... Volute - 56 Frame, 6.3” DIA ............. XP2, XP2e ........$ 92.74 A
2 92770735 ............... Volute - 48/56 Frame .............................XP3..............$ 66.24 A
3 SEAL-01 ................. 5/8” Pump Seal ............................XP2, XP2e, XP3....$ 9.26 A25-10
4 91694110 ................ 1 HP Impeller .........................................XP2..............$ 47.70 A
4 91694150 ............... 1.5 HP Impeller ......................................XP2..............$ 47.70 A
4 91694200 ............... 2 HP Impeller .........................................XP2..............$ 47.70 A
4 91694251 ............... 2.5 HP Impeller ......................................XP2..............$ 47.70 A
4 91694300 ............... 3 HP Impeller .........................................XP2..............$ 47.70 A
4 91694400 ............... 4 HP Impeller .........................................XP2..............$ 47.70 A
4 91698250 ............... 2.5 HP Impeller ......................................XP3..............$ 53.00 A
4 91698300 ............... 3 HP Impeller .........................................XP3..............$ 53.00 A
4 91698400 ............... 4 HP Impeller .........................................XP3..............$ 53.00 A
4 91695401 ............... 4 HP Impeller ........................................XP2e.............$ 53.00 A
4 91695150 ............... 1.5 HP Impeller .....................................XP2e.............$ 53.00 A
4 91695200 ............... 2 HP Impeller ........................................XP2e.............$ 53.00 A
4 91695250 ............... 2.5 HP Impeller .....................................XP2e.............$ 53.00 A
5 92830070 ...............Wear Ring ..............................................XP2..............$ 5.64 A
5 92830080 ...............Wear Ring ........................................ XP2e, XP3 ........$ 5.96 A
6 92200300 ............... O-Ring, Volute.................................. XP2, XP2e ........$ 5.64 A
6 92200301 ............... O-Ring, Volute..................................XP2 / XP2e........$ 5.32 A
6 92200310 ............... O-Ring, Volute........................................XP3..............$ 5.96 A
7 91231606 ............... Cover, Suction........................................XP2..............$ 47.70 A
7 91231702 ............... Cover, Suction........................................XP3..............$ 66.24 A
8 92200060 ............... O-Ring, Drain Plug.......................XP2, XP2e, XP3....$ 5.96 A
9 92290070 ............... Plug, Drain ...................................XP2, XP2e, XP3....$ 5.96 A
99730050 ............... Screw ...........................................XP2, XP2e, XP3....$ 3.38 A
2
4
5 6
9
7 8
3
2
4
5
6
8
10
7 9
3
2
4
5
6
8
10
7 9
3
