phone: 1-800-678-7178 fax: 1-800-270-9342
- 58 -
Central Spa
&
Pool Supply Ltd.
© 2012
W
ET
E
NDS
SKU Number
List Price Code Description
SKU Number
List Price Code Description
HIGH FLOW SIDE DISCHARGE
2” Centre Suction, 2” Side Discharge
310-1130SD
$ 128.02
A6-5 1 HP 48 Frame
310-1140SD
$ 128.02
A6-5 1.5 HP 48 Frame
310-1141SD
$ 128.02
A6-5 2 HP 48 Frame
310-1150SD
$ 128.02
A6-5 3 HP 48 Frame
310-1160SD
$ 128.02
A6-5 4 HP 48 Frame
VIPER WET END
2½” Centre Suction, 2½” Discharge
310-0170
$ 128.02
A8-5 3 HP 56 Frame
310-0140
$ 128.02
A8-5 4 HP 56 Frame
IMPELLERS
310-2200
$
37.72
A
4 HP
IRON MIGHT WET END
1½” Centre Suction, 1½” Side Discharge
310-1000
$ 152.26
A8-5 1/8 HP
PARTS
310-0900
$
29.30
A8-5 Impeller, 1/8 HP
805-0248
$
10.34
A
O-Ring Faceplate
HIGH FLOW SIDE DISCHARGE PUMP PARTS
Part Number
Description
List Price
Code
1
715-1201
................ Drain Plug ...................................................................$
2.94
A
2
805-0111
................. Drain Plug O-Ring.......................................................$
0.84
A
3
311-2140
................ Faceplate Volute .........................................................$ 32.38
A
4
805-0256
................ O-Ring.........................................................................$
7.32
A
5
319-1390
................ Impeller Sleeve 1 - 1.5 HP ..........................................$
8.88
A
6
310-3990
................ 3/4 HP Impeller ...........................................................$ 32.58
A
6
310-4000
................ 1 HP Impeller ..............................................................$ 32.58
A
6
310-4010
................ 1.5 HP Impeller ...........................................................$ 32.58
A
6
310-4020
................ 3 HP Impeller ..............................................................$ 32.58
A
6
310-4030
................ 2 HP Impeller ..............................................................$ 32.58
A
6
310-4050
................ 4 HP Impeller ..............................................................$ 37.72
A
7&8
SEAL-03
................. Seal, 5/8 Reverse Style ..............................................$
9.26 A12-10
9
315-2500
................ Volute Housing............................................................$ 53.86
A
10
313-1400
................ Slinger.........................................................................$
1.42
A
9
10
8
7 6
5 4
3
1 2
672-4350 barbed adapter will thread where the plugs are on these Wet Ends.
To get union size measure outside diameter of threads and subtract 1”
Eg. If measures 3” use 2” union
NOTE
Older parts not interchangeable with new parts
