Silicone Ignition Wire and GTO Cable
7mm Silicone Cable
Part # Description
80-41660 25' reel.
80-41661 100' reel.
80-41662 500' reel.
7mm GTO - 15 Cable
• Made of solid thermoplastic elastomer.
• UL & CSA listed
7mm Silicone Cable
• Advanced silicone rubber insulated ignition wiring material.
• Acceptable in igniter devices tested by the American Gas
Association Laboratories.
7mm GTO-15 Cable
Part # Description
80-41650 25' reel.
80-41652 100' reel.
80-41654 500' reel.
80-41656 1000' reel.
Applications
• Ovens
• Furnaces
• Air conditioning equipment
• Gas fired Appliances
Applications
• Transformer cable leads
• Ignition leads
• Wire connections not to exceed
specifications.
Specifications:
Wire Colour:
Wire Gauge:
Stranding:
Insulating Thickness:
Temperature:
Voltage:
O.D.:
UL Style:
CSA. Style:
Black
14 AWG
19 × 0.014" bare copper
0.098"
105°C
15 kVAC
0.270"± 0.002"
E135239
74278
Specifications:
Wire Colour:
Wire Gauge:
Stranding:
Insulating Thickness:
Temperature:
Voltage:
O.D.:
UL Style:
CSA. Style:
Red
18 AWG
16/30 nickel plated copper
0.113"
250°C
25 kVDC/ 10KV/ 60 Hz
0.274"± 0.002"
E64787
Not Applicable
80-41650
Illustrated
Not Exactly As
Illustrated
Ignition Wire
