Heating & A/C
Flame Detectors
Buss Bar Connectors
Buss Bars
Three types of solid brass buss bars are available in standard lengths
of 6", 8", 10" & 12". Longer lengths are available upon request.
• "F" series flat buss bars feature 3/8" wide × 0.040 thick 260 brass alloy.
• The "E" and "S" series rounded buss bars feature annealed 1/8"
diameter 303 stainless steel with 6-32 roll threads.
Type "F" flat buss bar.
Type "E" 1/8" diameter round buss bar. Similar to type S except
none threaded end is designed with a round hook.
C-10 Flame Detectors
Part #
Replaces
69-45610
Direct replacement
for Honeywell model
C554A (replacement
cell part # 130367,
120320 & 124607)
Flame Detectors
Flame detectors are hand crafted and tested twice, once before
assembly and once after. Flame detectors are made of a hermetic
glass to metal seal and cadmium sulfide for sensing. You'll find these
sensors to be the best of their kind.
Specifications
Maximum Voltage:
Max. Cell Surface Temp.:
Method of Sensing:
Maximum Resistance:
During Firing:
30 VAC
180°F
Cadmium Sulfide
Min. 300 Ohms
Max. 2000 Ohms
Buss Bar Connectors
Type "E"
Part #
Type "S"
Part #
Type "F"
Part #
Length
64-40309 64-40322 64-40316
6"
64-40311 64-40324 64-40318
8"
64-40313 64-40325 64-40319
10"
64-40315 64-40326 64-40320
12"
69-45610
Illustrated
69-45620
Illustrated
C-20 Flame Detectors
Part #
Replaces
69-45620
Replaces cell in White
Rodgers 956 and 956-1
assemblies (old style)
Type "S" 1/8" diameter round straight buss bar
threaded one end.
64-40322
Illustrated
64-40318
Illustrated
Flame Detectors
