Electrical
Control Switches
• 3 Amp, 125 Volt.
• 1 Amp, 250 Volt.
Control Switches
Fig. 2
Fig. 1
Fig.3
Toggle Switches
Rocker Switches • Snap-in Mount
Push Button Switches
• 2 Position - On / Off.
Part #
Description
29-150
Phenolic knob 9/16" nipple
29-151-6
Metal knob 3/8" nipple
• 3 Position - Off / On / On.
Part #
Description
29-151-2
2 Speed switch metal knob 7/16" nipple
Rotary Switches
• 2 Position - On / Off.
Part #
Description
29-151-8
Phenolic knob 3/8" nipple
Part #
Circuit
Function Amps Terminals Fig.
29-TSH11
SPST 2 - On / Off
20
2
1
29-TSH12
SPDT 2 - On / On
20
3
1
29-TS102
SPDT 3 - On / Off / On
15
3
2
29-TSM12
SPDT 3 - Off / On / On*)
15
4
3
29-TS21
DPST 2 - On / Off
15
4
3
29-TS22
DPDT 2 - On / On
15
6
6
29-TS202
DPDT 3 - On / Off / On
15
6
3
29-158-5
SPST 2 - On / Off white 20
2
4
29-158-6
SPST 2 - On / Off black 20
2
4
29-158-10
SPST 2 - On / Off black 3
2
5
(On*) - Momentary Contact
Mini Rockers
Part #
Colour
Function
Amps 1⁄4"Spades Fig.
29-159-1
Black 2 - On / Off
15
3
1
29-159-3
Black 2 - On / Off
10
2
2
29-159-4
White 2 - On / Off
10
2
2
29-159-5
Black 3 - On / Off / On
10
3
2
29-159-6
White 3 - On / Off / On
10
3
2
‡ Lighted
Standard Rockers
Part # Colour
Function Amps 1⁄4" Spades Fig.
29-159-13
Black 2 - On / Off
6
4
3
29-159-15
Black 3 - On / Off / On
6
5
3
(On*) Momentary Contact
29-151-6
Illustrated
29-151-2
Illustrated
29-151-8
Illustrated
Fig. 1
Fig. 2
Fig. 5
Fig. 3
Fig. 4
Fig. 6
