Electrical
Metallic-Fusible & Non Fusible A/C
Disconnects
Drop-Down Door (Fusible & Pull-Out)
• Drop-down, swing-out door with lockable latch.
• 240V / 60 Amp
• 19.84 × 13.18 × 8.10cm (7 13/16" × 5 3/16" × 3 3/16")
• Easy-off, easy-on disconnect pullout
• NEMA 3R rainproof enclosure for outdoor use
• For use with aluminum or copper conductors
• Powder coat finish on rugged steel construction
• Knockouts provided on back, bottom and side for multiple
applications
• cUL listed
Fusible Pull-Out
• Pull-out & pocket! Now that's service security!
Part #
Volts Amps Phase Weight
11-6300
240 60
1 3.7 lbs.
Pull-Out (Lift-Up Door)
• Pull-out & pocket! Now that's service security!
Part #
Volts Amps Phase Weight
11-6200
240 60
1 3.6 lbs.
11-6300
&
11-6200
Door Closed
11-6200
Pull-Out
11-6300
60 Amp Pull- Out
Fusible
Air Conditioner Electrical Disconnect Switches
Fusible
Metallic-Non Fusible Air Conditioner Electrical
Disconnect & GFCI Receptacle Combination
• Available with pullout or non-automatic switch.
• Lift-up removable door for easy wiring access.
• Single phase.
• 12.7 × 17.8 × 10.2cm (5" × 7" × 4")
- compact NEMA 3R rated.
• Six (1⁄2" × 3⁄4" × 1") knockouts reduce installation time.
• Heavy galvanized G90 steel with highest quality electro-deposition
finish resists corrosion and fading.
• UL & cUL approved.
Non Automatic Switch
• Duplex 15 amp GFCI receptacle included.
Part #
HP Volts Amps Phase AIC Rating Weight
11-U065NA1010
10 240 60
1
10,000 4.5 lbs.
Pull-Out
• Duplex 15 amp GFCI receptacle included.
Part #
HP Volts Amps Phase AIC Rating Weight
11-U065P010
10 240 60
1
10,000 4.5 lbs.
Air Conditioner Electrical Disconnect & GFCI
11-U065NA1010
Switch
11-U065P010
Pull-Out
A/C Disconnects
