145
Heating & A/C
Combustion Chamber Liners
63-3WETPAK
Illustrated
63-D11
Illustrated
63-DP9, DP11,
DP13 & DP15
Models
63-DP16 & DP20
Models
63-10WETPAK
Illustrated
Wet Paks
• Seamless design complete with a bottom.
• Pliable yet self supporting in a vertical position.
Pre Dried
• Formed to a uniform thickness & density while maintaining a
hardness which has exceptional handling strength.
• Easy to cut means more versatility in nozzle opening placement.
Features:
• Fast easy installation - less than 30 min.
• Low conductivity - high efficiency.
• High sound absorption.
• Lightweight: 5% of conventional firebrick.
• High heat resistance (up to 2300°F).
• Superior to steel brick or castable
chambers.
• Individually sealed & packaged.
• Comes with instructions.
• Wall thickness 1/2" nominal.
Preshaped Wet Paks
Part #
G.P.H
Inside
Diameter
Outside
Diameter
Height
Weight
63-09WETPAK
0.50 to 0.75 8"
9"
15.5"
4.0 lbs.
63-10WETPAK
0.75 to 1.00 9"
10"
15.5"
5.0 lbs.
63-11WETPAK
1.00 to 1.25 10"
11"
15.5"
6.0 lbs.
63-12WETPAK
1.25 to 1.50 11"
12"
15.5"
6.5 lbs.
63-13WETPAK
1.50 to 2.00 12"
13"
15.5"
7.0 lbs.
63-14WETPAK
2.00 to 2.50 13"
14"
15.5"
7.5 lbs.
63-16WETPAK
2.50 to 2.75 15"
16"
15.5"
8.5 lbs.
Pre Dried
Part #
G.P.H.
Inside
Diameter
Outside
Diameter
Height Weight
63-D09
0.50 to 0.75
8"
8"
12.25" 2.25 lbs.
63-D10
0.75 to 1.00
9"
10"
12"
3.0 lbs.
63-DP09
0.65 to 0.85
9"
10.5"
15"
5.0 lbs.
63-D11
1.00 to 1.25
10"
11"
12"
3.5 lbs.
63-DP11
1.00 to 1.25
11"
12.5"
15"
6.5 lbs.
63-D12
1.25 to 1.50
11"
12"
14"
4.0 lbs.
63-D13
1.50 to 2.00
12"
13"
14" 4.25 lbs.
63-D14
2.00 to 2.50
13"
14"
16"
5.0 lbs.
63-DP13
1.35 to 1.75
13"
14.5"
15" 8.25 lbs.
63-DP15
1.75 to 2.00
15"
16.5"
15"
9.5 lbs.
63-DP16
1.75 to 2.25 10.5" × 15"
13" × 17.5"
15"
16 lbs.
63-DP20
2.25 to 3.00 12" × 19.5"
14.5" × 22"
16"
17 lbs.
OEM Replacements
63-D20
Grimsby 97 - 77
10.5" × 10.5" 11.5" × 11.5" 12"
3 lbs.
63-D21
Grimsby 117 - 77
10.5" × 10.5" 11.5" × 11.5" 12"
3 lbs.
63-D22
Grimsby 140 - 79
12" × 12.25" 13" × 13.5"
13"
4.5 lbs.
63-D23
Grimsby 158 - 79
11.75" × 11.88" 13" × 13.88"
12"
4.5 lbs.
63-D24
Grimsby W - 196
9.125" × 9" 10.125" × 10" 10.25" 3 lbs.
63-D30
Esso #110
5 Component Set
12 lbs.
63-D31
Esso #150
5 Component Set
15 lbs.
Wet Pak Sheets
Part #
G.P.H
Inside
Diameter
Dimensions
Weight
63-1WETPAK
1.25
Flat Sheet
Sizes
14" x 48" × 0.5"
9.0 lbs.
63-2WETPAK
2.50
1pc. 14" x 48"× 0.5" &
1pc. 16" x 16"× 0.5"
10.0 lbs.
63-3WETPAK
2.65
1pc.16" x 48"× 0.5" &
1pc. 16" × 16"× 0.5"
10.25 lbs.
Combustion Chambers
